AOC I2369Vm Service Manual

52
Printing,LM230WF3-S2D2
7250L-0853E
NITTO, 5000NS, White, 60*8*0.16,
Fixing
E2436L 6925L-0054A
LM230WF3(SJF1，S2F2/S2F6/S2FB)
6925L-0047A
LM230WF3(SJF1，S2F2/S2F6/S2FB)
2nd source
6060L-3238A LM230WF3-SJF1-K31
6061L-2629A LM230WF3-SJF1-K31
0ILUL-0285A
LS0608MEH3-C6LX, LUSEM, 720, 6BIT,
EPI PGC, C_B, R/TP, 35MM, 5PF,
UPILEX, ENG
6308L-5261A
LSBXSPKHXAX6-02300T26,
530.1*300.9, LGC, S, B, X, S, P, K, H, X,
A, X6, 02300, Top, 26
6308L-5262A
LSXXSPKHXAX6-02300B26,
512.4*289.4, LGC, S, X, X, S, P, K, H, X,
A, X6, 02300, Bottom, 26
6884L-0090A
CP12941-20YA, SONY,
1.5MMX300MM, 20UM
6884L-0034A
CP5420ISL, SONY, L=1.5MMX300M,
T=20
2nd source
6884L-0152A
AC-11600-14, HITACHI, 300MX1.5MM,
14UM
2nd source
6884L-0153A
(AC-11600-14, HITACHI, 300MX2.0MM,
14UM)
2nd source
6884L-0053A
CP2420ISL,L=1.5MMX300M, T=18UM,
SONY
2nd source
7752L-0004A KTEM-UV3000, KEC
7752L-0005A (HC-305, HI-CHEMICAL) 2nd source
6871L-3250B
Source, Single, None-C/SKD,
LM230WF3-SJF1-K31, Single Side
C122,C345,C347,C348,C
354,C74,C85
0CH2102K562 1NF 50V K X 1608 R/TP
C350,C351,C353 0CH2104K562 0.1UF 50V K X7R 1608 R/TP
C100 0CH2153K562 15nF, K, 50V, X7R, 0.9mm, 1608, R/TP
C343 0CH2473H562 47nF, K, 25V, X7R, 0.9mm, 1608, R/TP
C81 0CH2474D572
0.47uF, K, 10V, X5R, 0.95mm, 1608,
R/TP
C5,C6,C7 0CH2A-0004A
MLCC ** 10uf，
K,10V,X5R,1.8mm,3216,R/TP
C346 0CH2A-0007A
1U F, 10 Volt, K PER, X5R(JB), 1608
R/TP, T=0.9(MAX)

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
