AOC I2369Vm Service Manual

53
C50 0CH2A-0008A
MLCC ** 4.7uf，
K,25V,X5R,0.95mm,3216,R/TP
C102,C103,C340,C41,C8
8,C89,C90
0CH2A-0013A
MLCC ** 10uf，
K,25V,X5R,1.8mm,3216,R/TP
C110,C355,C51,C87 0CH2A-0015A 1uF, K, 25V, X5R, 0.9mm, 1608, R/TP
C181,C183,C217,C218,C
219,C220,C221,C227,C3
12,C322,C332,C342
0CH2A-0030A 1uF, K, 10V, X5R, 0.55mm, 1005, R/TP
C71,C94 0CH2A-0072A
MLCC ** 10uf，
K,10V,X5R,1.35mm,2012,R/TP
C349 0CH2A-0073A
0.1uF, K, 16V, X7R, 0.55mm, 1005,
R/TP
C120,C121,C82 0CH2A-0088A 3.3nF, K, 50V, X7R, 0.9mm, 1608, R/TP
C170,C171,C172,C173,C
174,C180,C182,C311,C3
21,C331,C341
0CH2A-0091A 1uF, K, 25V, X5R, 0.6mm, 1005, R/TP
C80 0CH2A-0148A 10UF, K, 10V, X5R, 0.9mm, 1608, R/TP
C52,C53 0CH2A-0164A
0.47UF, K, 25V, X5R, 0.95mm, 1608,
R/TP
C35,C36 0CH5121K412 120PF, J, 50V, 1608, R/TP, 0.9mm
D3,D8 0DHZL-0008B BAV99-7-05-F, DIODES, SOT-23, R/TP
ZD1 0DHZL-0076A SDZ3V3D, AUK, SOD-323, R/TP
D1 0DHZL-0095A RB050M-30, ROHM, PMDU, R/TP
D10 0DHZL-0131A SDB0740, AUK, SOT-23, R/TP
D11 0DHZL-0142A SD05, SEMTECH, SOD323, R/TP
F1 0FSLO-0013A F0603HI3000V032T, AEM, Ceramic
U1 0ISGL-0008C
M24C04-RDW, STmicroeletronics, 4K,
5ms, TSSOP, R/TP, 8
US1 0ISML-0024A
SM4043, SILICON MITUS, MNT, VDD
BOOST + VGH BOOST + VGL C/P +
VCC BUCK + L/S + OPAMP +
DISCHARGING + GPM + PVCOM, QFN,
R/TP, 48
UC1 0ITLL-0083A
TL2358EP, TLI, LVDS, 6/8, 2, EPI, 6,
3/4, DRD, SGIP, AFRC, DGA, SD, SM,
SFA, Z-INV, ESD, LOWELL13, MLF, TR,
48
L1 0LCAA-0039A
DP8L18F-100M, COIL MASTER, 10uH,
M=20%, 1.9A, 114m Ohm, 8.1x6.8x1.8,
R/TP
L2,L3 0LCAA-0089A CMI-DOP3910NH-6R8M, COIL

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
