MASTER, 6.8 UH, M=20%, 0.9 A, 0.26
OHM, 3.9X3.9X1 (MM), R/TP
R232 0RH0000B622 0 ohm, 1/16W, 1005, 5%, R/TP
R101,R105,R130,R200,R
203,R205,R248,R250,R2
60,R261,R267,R268,R60,
R65,R82,R90
0RH0000C622 0 OHM 1/10W 0603 0.05R MAX
R85 0RH0102C422 10 OHM 1/10W 0603 1%
R259,R279 0RH0221C622 2.2 OHM 1/10W 0603 5%
R263,R264,R265,R266,R
269,R270,R271,R272,R2
73,R274,R275,R276
0RH0472C422 47 OHM 1/10W 0603 1%
R262 0RH1000B422 100 ohm, 1/16W, 1005, 1%, R/TP
R104,R2,R3,R56 0RH1000C422 100 OHM 1/10W 0603 1%
R254 0RH1001C422 1K OHM 1/10W 0603 1%
R16,R30,R55 0RH1002C422 10K OHM 1/10W 0603 1%
R172,R181 0RH1003C422 100K OHM 1/10W 0603 1%
R253 0RH1102C422 11K OHM 1/10W 0603 1%
R186 0RH1202C422 12K OHM 1/10W 0603 1%
R111 0RH1302C422 13K OHM 1/10W 0603 1%
R180 0RH1501C422 1.5K OHM 1/10W 0603 1%
R121 0RH1502C422 15K OHM 1/10W 0603 1%
R170 0RH1503C422 150K ohm, 1/16W, 1608, 1%, R/TP
R61 0RH1601C422 1.6K OHM 1/10W 0603 1%
R93 0RH1801C422 1.8K OHM 1/10W 0603 1%
R183,R256 0RH2001C422 2K OHM 1/10W 0603 1%
R106,R252 0RH2002C422 20K OHM 1/10W 0603 1%
R103 0RH2201C422 2.2K OHM 1/10W 0603 1%
R123 0RH2203C422 220K ohm, 1/16W, 1608, 1%, R/TP
R13,R14 0RH2401C422 2.4K OHM 1/10W 0603 1%
R280,R80 0RH3002C422 30K OHM 1/10W 0603 1%
R9 0RH3300C422 330 ohm, 1/16W, 1608, 1%, R/TP
R120 0RH3301C422 3.3K OHM 1/10W 0603 1%
R187 0RH3902C422 39K OHM 1/10W 0603 1%
R87 0RH4301C422 4.3K OHM 1/10W 0603 1%
R15 0RH4700C422 470 OHM 1/10W 0603 1%
R110,R86 0RH4702C422 47K OHM 1/10W 0603 1%
R257 0RH5100C422 510 OHM 1/10W 0603 1%
R100,R185,R188,R91 0RH5101C422 5.1K OHM 1/10W 0603 1%
R171,R70 0RH5102C422 51K OHM 1/10W 0603 1%
R102 0RH5602C422 56K OHM 1/10W 0603 1%
