AOC I2369Vm Service Manual

55
R229,R230 0RH5603C422 560K ohm, 1/16W, 1608, 1%, R/TP
R81 0RH6202C422 62K OHM 1/10W 0603 1%
R89 0RH7501C422 7.5K OHM 1/10W 0603 1%
R122,R249,R255,R92 0RH8201C422 8.2K OHM 1/10W 0603 1%
R88 0RH9100C422 910 OHM 1/10W 0603 1%
R251,R64 0RH9101C422 9.1K OHM 1/10W 0603 1%
FL35,FL36 6200C-0014A
BLM18EG601SN1D, MURATA, 0.35
Ohm, 1.6X0.8, R/TP
FL1,FL2,FL37 6200L-J015A BLM18PG300SN1D
RT1 6322L-0012A 22K, +-3%, -, 0.21 MA, 3950, 1005, R/TP
CN1 6630L-0180A IS100-L30O-C23, UJU, 30PIN, 1.0MM
6870S-1617A
LM230WF3-SSB1-KL1, 2L, 0.6,
428.3*27.0, 6, J, Source, HF, Single Side
6884L-0061A CP20631-35YA, 2.0MMX300M, SONY
6884L-0044B DP2252KSL(2.0MMX300M), SONY 2nd source
6884L-0044C AC-9825R-45(2.0MMX300M), HITACHI 2nd source
6884L-0083A
CP21831-35YA, SONY, 2.0 X 300M,
35UM
2nd source
6884L-0174A EMA8888E, LGIT, 300M, 75 ΜM 2nd source
7526L-0001A DS 103, NC Chem., UV
7250L-0484P
HWASUNG SEALING, STN1026WR(P),
Gray, 12*30*0.11, Electric Conductivity
756GQCCB0AA3690000 MCU ASS'Y
U402 056G2233-37
IC FLASH MX25L4006EM1I-12G 4Mb
SOP-8 MXIC
SMTCC-U402 100GANJD001YT1 AOC I2369VM
A33G1429--1-1C0100 Power_lens
A33G1437AED-1B0100 Key_button
A33G1490AED-1B0100 Stand_rear
A34G3135-OPA1B0130 Bezel
A34G3136AED-1B0100 Middle_frame
A34G3137AED-3B0130 Rear_cover
A34G3138AED-1B0100 Hinge_cover
A34G3139AED-1B0100 Stand_front
A34G3141-OP-1B0130 Base
AM1G1740-10225-CR3 screw
CBPCCV2A1Q1 CONVERTER BOARD
CN702 033G3802-4B--Y---L WAFER 4P 2.0MM XIANGLONG
CN402 033G3802-6B--Y---L WAFER 6P 2.0MM XIANGLONG
033G3802-6B--Y WAFER 6P 2.0MM XINYA 2nd source
CN701 033G3802-9B--Y WAFER 9P 2.0MM XINYA

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
