AOC I2369Vm Service Manual

56
033G3802-9B--Y---L WAFER 9P 2.0MM XIANGLONG 2nd source
CN406 033G801930F-CH---L WAFER 30P 1.0MM XIANGLONG
033G801930F-CH--JS WAFER 30P 1.0MM JINGSHI 2nd source
R711,R716 061G152M22964B--SY
RST MOF 2R2 5% 2W
RSS02J2R20C150NH
C629,C706,C707,C710,C
711,C715
067G-4051013LB
EC 100uF +-20% 16V 5*11mm 4000Hr
LELON
067G-3051013PB
EC 105℃ 100uF M 16V 5*11mm
2nd source
C450,C615,C616,C704 067G305S2213HV
EC 220UF 20% 16V 6.3*7
SHC221M1CE07AM4HT235 HER-MEI
CN104 088G-34320EVFA DP CONNECTOR 20P FOXCONN
CN101 088G-35315FVXH
D-SUB CONN WITH SCREW 15P
BLUE XIANHE
088G-35315FVCL
D-SUB CONN WITH SCREW 15P
BLUE CL
2nd source
CN601 088G302G5B2VYG PHONE JACK 5P BLACK YCG
088G302G5B2VCL PHONE JACK 5P BLACK CL 2nd source
CN602 088G302G5G1VYG PHONE JACK 5P GREEN YCG
088G302G5G1VCL PHONE JACK 5P GREEN CL 2nd source
X401 093G--22-51-YC
DIODE CRY 12MHZ
YC-49S-12M30PF30PPM25ohm YC
CN603 311GW200A04ABX WAFER 4P 2.0mm XINYA
311GW200A04ABL WAFER 4P 2.0MM XIANGLONG 2nd source
H40G-45762429A CBCP Label for EE
SMTCCV2A1Q1 MAIN BOARD FOR SMT
U702 056G-563121
IC LDO G1084-33TU3Uf 5A/3.3V
TO-263T GMT
U707 056G-563127
IC LDO G1117-25T63Uf SOT-223
GMT
U706 056G-563145
IC LDO AZ1117D-1.2TRE1 1A/1.15V
BCD
U509 056G-581--9
IC Power Switch G5250K1T1U SOT23-5
GMT
U601 056G-616112
IC AUDIO APA2606NAI-TRG 2.8W
SSOP-24P Anpec
U114,U115,U116,U503,U
504,U507,U508,U510
056G-662-18
IC ESD AZ1045-04F.R7G
DFN2510P10E Amazing
056G-662-21 IC ESD AOZ8804DI DFN-10 AOS 2nd source
U101,U502,U505 056G1133-34--1
IC EEPROM M24C02-RMN6TP 2Kb
SO-8 ST
056G1133161 IC EEPROM AT24C02C-SSHM-T 2Kb 2nd source

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
