AOC I2369Vm Service Manual

57
SOIC-8 Atmel
U403 056G1133-56
IC EEPROM M24C16-WMN6TP 16Kb
SOIC-8 ST
356G1133016182
IC EEPROM AT24C16C-SSHM-T 16KB
SOIC-8
2nd source
U402 056G2233-37
IC FLASH MX25L4006EM1I-12G 4Mb
SOP-8 MXIC
Q405,Q501,Q503,Q505,Q
601,Q702
057G-417511
TRA MMBT3904 0.2A/40V SOT-23
BLUE ROCKET
057G-417518
TRA LMBT3904LT1G 0.2A/40V
SOT-23 LRC
2nd source
Q401,Q402,Q504,Q602 057G-417512
TRA MMBT3906 0.2A/40V SOT-23
BLUE ROCKET
057G-417517
TRA LMBT3906LT1G -0.2A/-40V
SOT-23 LRC
2nd source
Q502,Q506 057G-759-2A-HF MOSFET 2N7002H SOT-23 Panjit
057G-759-2A
MOSFET 2N7002 0.2A/60V SOT-23
Panjit
2nd source
Q403 057G-763940
MOSFET AO3401A 4.2A/30V SOT-23
AOS
R177,R179,R180,R181,R
182,R406,R407,R417,R4
23,R441,R442,R502,R50
3,R504,R505,R506,R507,
R508,R509,R521,R522,R
523,R524,R525,R526,R5
27,R529,R552,R614
061G0402000-JI
TEST ONLY RST 0402 0.05R MAX
1/16W TA-I
061G0402000-JY
RST CHIPR 0 OHM -5% 1/16W
YAGEO
2nd source
R103,R109,R115,R515,R
536,R651,R652,R653,R6
54
061G0402100-JY
RST CHIPR 10 OHM +-5% 1/16W 0402
YAGEO
061G0402100-JT
RST CHIPR 10 OHM -5% 1/16W 0402
TZAI YUAN
2nd source
R619 061G04021001FY RST CHIPR 1KOHM 1% 1/16W YAGEO
R112,R119,R120,R188,R
192,R424,R429,R432,R4
33,R434,R501,R528,R54
2,R550,R603,R606,R649,
R704
061G0402101-JY
RST CHIPR 100 OHM +-5% 1/16W 0402
YAGEO
061G0402101-JT RST CHIPR 100 OHM -5% 1/16W 2nd source

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
