AOC I2369Vm Service Manual

58
0402 TZAI YUAN
R178,R411,R412,R413,R
485,R486,R511,R551,R6
20,R621,R622
061G0402102-JY
RST CHIPR 1 KOHM +-5% 1/16W 0402
YAGEO
061G0402102-JT
RST CHIPR 1 KOHM -5% 1/16W 0402
TZAI YUAN
2nd source
R470,R471 061G04021021FT RST 0402 1.02K 1% 1/16W TZAI YUAN
R401,R403,R404,R425,R
479,R520,R541,R547,R6
05,R607,R623,R627,R65
0,R708,R714
061G0402103-JI
RST CHIPR 10 KOHM +-5% 1/16W
0402 TA-I
061G0402103-JY
RST CHIPR 10 KOHM -5% 1/16W
0402 YAGEO
2nd source
R123,R190,R480,R556,R
557,R601
061G0402104-JY
RST CHIPR 100 KOHM +-5% 1/16W
0402 YAGEO
061G0402104-JT
RST CHIPR 100 KOHM -5% 1/16W
0402 TZAI YUAN
2nd source
R175,R186,R405 061G0402105-JT
RST CHIPR 1 MOHM +-5% 1/16W 0402
TZAI YUAN
061G0402105-JY
RST CHIPR 1 MOHM -5% 1/16W 0402
YAGEO
2nd source
R646 061G04021202FT
RST CHIPR 12 KOHM +-1% 1/16W
0402 TZAI YUAN
R439,R440 061G0402204-JT
RST CHIPR 200 KOHM +-5% 1/16W
0402 TZAI YUAN
061G0402204-JI RST 0402 200K 5% 1/16W TA-I 2nd source
R121,R122,R414,R419 061G0402222-JT
RST CHIPR 2.2 KOHM +-5% 1/16W
0402 TZAI YUAN
061G0402222-JY
RST CHIPR 2.2 KOHM -5% 1/16W
0402 YAGEO
2nd source
R114,R478,R514,R535,R
628,R715
061G0402223-JY
RST CHIPR 22 KOHM +-5% 1/16W
0402 YAGEO
061G0402223-JT
RST CHIPR 22 KOHM -5% 1/16W
0402 TZAI YUAN
2nd source
R612 061G04023001FY RST 0402 3K 1/16W YAGEO
R645 061G04023002FT
RST CHIPR 30 KOHM +-1% 1/16W
0402 TZAI YUAN
R543 061G0402304-JT
RST CHIPR 300 KOHM +-5% 1/16W
0402 TZAI YUAN
R613 061G04023302FY
RST CHIPR 33 KOHM +-1% 1/16W
0402 YAGEO

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
