AOC I2369Vm Service Manual

59
R519,R540 061G0402333-JT
RST CHIPR 33 KOHM +-5% 1/16W
0402 TZAI YUAN
061G0402333-JY
RST CHIPR 33 KOHM -5% 1/16W
0402 YAGEO
2nd source
R467,R468,R469 061G0402392-JT
RST CHIPR 3.9 KOHM +-5% 1/16W
0402 TZAI YUAN
061G0402392-JY
RST CHIPR 3.9KOHM -5% 1/16W
0402 YAGEO
2nd source
R102,R104,R106,R111,R
117,R427,R428,R516,R5
18,R538,R539
061G0402470-JY
RST CHIPR 47 OHM +-5% 1/16W 0402
YAGEO
061G0402470-JT
RST CHIPR 47 OHM -5% 1/16W 0402
TZAI YUAN
2nd source
R408,R626 061G0402471-JT
RST CHIPR 470 OHM +-5% 1/16W 0402
TZAI YUAN
061G0402471-JY
RST CHIPR 470 OHM -5% 1/16W
0402 YAGEO
2nd source
R101,R113,R448,R449,R
450,R477,R512,R513,R5
33,R534,R548,R549,R71
0
061G0402472-JY
RST CHIPR 4.7 KOHM +-5% 1/16W
0402 YAGEO
061G0402472-JT
RST CHIPR 4.7 KOHM -5% 1/16W
0402 TZAI YUAN
2nd source
R546,R553,R554,R558 061G0402473-JY
RST CHIPR 47 KOHM +-5% 1/16W
0402 YAGEO
061G0402473-JT
RST CHIPR 47 KOHM -5% 1/16W
0402 TZAI YUAN
2nd source
R105,R110,R116 061G0402750-JY
RST CHIPR 75 OHM +-5% 1/16W 0402
YAGEO
061G0402750-JT
RST CHIPR 75 OHM -5% 1/16W 0402
TZAI YUAN
2nd source
R608,R609 061G0402752-JY
RST CHIPR 7.5 KOHM +-5% 1/16W
YAGEO
061G0402752-JT
RST CHIPR 7.5 KOHM -5% 1/16W
0402 TZAI YUAN
2nd source
R118,R426 061G0603000-JT
RST CHIP MAX 0R05 1/10W TZAI
YUAN
061G0603000-JY RST CHIPR MAX0R05 1/10W YAGEO 2nd source
R602,R604 061G0603111-JT
RST CHIPR 110 OHM +-5% 1/10W 0603
TZAI YUAN
R421 061G0603331-JI RST CHIPR 330 OHM +-5% 1/10W 0603

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
