AOC I2369Vm Service Manual

60
TA-I
061G0603331-JY
RST CHIPR 330 OHM -5% 1/10W
0603 YAGEO
2nd source
R416 061G0603471-JI
RST CHIPR 470 OHM +-5% 1/10W 0603
TA-I
061G0603471-JY
RST CHIPR 470 OHM -5% 1/10W
0603 YAGEO
2nd source
R476 061G1206301-JT
RST CHIPR 300 OHM 1/4W TZAI
YUAN
C642,C643,C644,C645 065G040210232K---A
MLCC 0402 1000pF +-10% 50V X7R
SAMSUNG
065G040210232K---Y
MLCC 0402 1000pF -10% 50V X7R
YAGEO
2nd source
C145,C147,C148,C149,C
150,C402,C403,C405,C4
06,C408,C409,C411,C41
3,C414,C416,C418,C419,
C421,C424,C441,C442,C
451,C452,C501,C504,C5
07,C623,C625,C628,C70
8,C709,C712,C713
065G040210412K---M
MLCC 0402 0.1uF +-10% 16V X7R
MURATA
C601,C606,C607,C610,C
617,C618,C641
065G0402105A5K---M
MLCC 0402 1uF +-10% 10V X5R
MURATA
C116,C117 065G040222031J---A
MLCC 0402 22pF +-5% 50V NPO
SAMSUNG
C439,C440,C611,C614,C
619,C626
065G040222131J---T
MLCC 0402 220pF +-5% 50V NPO
TAIYO YUDEN
C111,C435,C437,C453,C
503,C508
065G040222415K---A
MLCC 0402 0.22uF +-10% 16V X5R
SAMSUNG
C426,C427 065G040247031J---A
MLCC 0402 47pF +-5% 50V NPO
SAMSUNG
C604,C605 065G040247131J---Y 0402 470pF J 50V NP0
065G040247131J---A
MLCC 0402 470PF -5% 50V NPO
SAMSUNG
2nd source
C102,C104,C107,C109,C
110,C113,C506
065G040247312K---A
MLCC 0402 47nF +-10% 16V X7R
SAMSUNG
C103,C108,C112 065G040250931C---Y
MLCC 0402 5pF +-0.25pF 50V NPO
YAGEO
C602,C603,C609,C624 065G060347412K---T
MLCC 0603 0.47uF +-10% 16V X7R
TAIYO YUDEN
C146,C401,C404,C407,C 065G0805106A5K---M MLCC 0805 10uF +-10% 10V X5R

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
