AOC I2369Vm Service Manual

61
410,C412,C434,C608,C6
20,C622
MURATA
C714 065G080522512K---M
MLCC 0805 2.2uF +-10% 16V X7R
MURATA
C415,C417,C420,C422 065G080547515K---M
MLCC 0805 4.7uF +-10% 16V X5R
MURATA
HDCP-U402 070GHDCP500HDC HDCP CODE
FB106,FB401,FB403,FB4
04,FB405,FB406,FB407,F
B408,FB409,FB413,FB41
4,FB601,FB602,FB603,F
B604,FB605,FB606,FB70
2
071G-56K121--M CHIP BEAD
071G-56K121-TA
CHIP BEAD 120R/6000mA
HCB2012KF-121T60
2nd source
FB101,FB415,FB501,FB5
02
071G-59G301-TA
CHIP BEAD 300OHM 200mA
FCM1608KF-301T02
071G-59G301--M CHIP BEAD 0603 300R 25% 200mA 2nd source
FB102,FB103,FB104 071G-59K190--M CHIP BEAD 0603 19R/500mA
071G-59K190-TA
CHIP BEAD 0603 19R 25% 500mA
FCB1608KF-190T05 TAI-TECH
2nd source
CN501,CN502 088G-34019H-VT HDMI HEADER 19P TECONN
088G-34019H-VA HDMI HEADER 19P VAST 2nd source
D501,D502 093G--60515--L
DIDOE SCHOTTKY LBAT54CLT1G
0.2A 30V SOT-23 LRC
093G--60518SEM
DIODE SCHOTTKY BAT54C-HAF 0.2A
30V SOT-23 SEMTECH
2nd source
D101 093G--64-42-PP DIODE BAV70 0.125A/85V SOT-23 NXP
093G--64-42--L
DIODE LBAV70LT1G 0.15A/75V
SOT-23 LRC
2nd source
ZD101,ZD501,ZD504 093G-39S940--T
DIODE ZD GLZ5.6B MINI-MELF
5.6V/0.5W LL-34 PANJIT
093G-39GA01--T
DIODE ZD RLZ5.6B 5.6V/0.5W
SEMTECH
2nd source
D601 093G-64S522SEM
DIODE SWITCHING 0.15A/75V LL4148
SEMTECH
093G--6432P
DIODE SWITCHING LL4148
0.15A/100V PANJIT
2nd source
D102 093G3004--2
DIODE SCHOTTKY SR34 3A/40V SMB
PANJIT
U401 356G0562128B32 IC SCALER NT68859UMFG LQFP 128

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
