AOC I2369Vm Service Manual

62
NOVATEK
U102,U103,U501,U506 356G0662056
IC ESD AT2042K6-5.0TRG1 SOT-23-6
BCD
056G-662-52
IC ESD PROTECT AZC398-04S.R7G
SOT23-6 Amazing
2nd source
E715 715G5812M0D000004I
Main PCB FR4 DS 140*110*1.6MM 3 联
板 兴达
715G5812M0D000004K
Main PCB FR4 DS 140*110*1.6MM 3 联
板 景旺
2nd source
715G5812M0D000004Q
Main PCB FR4 DS 140*110*1.6MM 3 联
板 科荣
2nd source
F40G215I615-9A
Rating label for 69 系列（EU&EPI)
F40GKA01624-2A Shipping label
F40GYA0361539B
POP LABEL (EPA+win8) 69 系列
F40GYA0361540A EU energy LABEL FOR I2369VM
F44GDF45101 EPS
F44GDF45201 EPS
F44GDF45615-1A-JVS Carton for I2369VM WW
F70G22C161512B
I2269VWM,I2269VW,I2369V,I2369VM,I
2769V,I2769VM CD MANUAL
CN603 F78G311A501YAA
SPK 4OHM 2.5W 57.5*23 405*265mm
SU
F78G311A501VAA
SPK 4OHM 2.5W 57.5*23 405*265mm
VECO
2nd source
E08903 F89G-184LAA500 HDMI CABLE 1800MM hongshuo
089G-184GAA500 HDMI CABLE 1800MM GREATLAND 2nd source
089G-184CAA500 HDMI CABLE 1800MM COMLINK 2nd source
E09502 F95G176H-10364
FFC CABLE 10PIN 193MM P0.5MM
HONGLIN
F95G176J-10364
FFC CABLE 10PIN 193MM P0.5MM
KOTL
2nd source
F95G176X-10364
FFC CABLE 10PIN 193MM P0.5MM
WENXIN
2nd source
F95G176T-10364 FFC CABLE 10PIN 193MM P0.5MM DIY 2nd source
E09501 F95G179X30N267
FFC CABLE 30PIN 398MM 1.0MM
WENXIN
F95G179J30N267
FFC CABLE 30PIN 398MM 1.0MM
KOTL
2nd source
F95G179H30N267
FFC CABLE 30PIN 398MM 1.0MM
HONGLIN
2nd source
F95G179T30N267 FFC CABLE 30PIN 398MM 1.0MM DIY 2nd source

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
