AOC I2369Vm Service Manual

63
E09503 F95G8014-6D150
WIRE HARNESS 6P-6P 450MM
GREATLAND
F95G8014-6X150 WIRE HARNESS 6P-6P 450MM XINYA 2nd source
F95G8014-6T150 WIRE HARNESS 6P-6P 450MM DIY 2nd source
KEPCCQR5 KEY BOARD
SW001 377G05005C20XL DOME SW
SMTK01 SMTKEPCCQR5 KEY BOARD FOR SMT
SMTKEPCCQR5W KEY BOARD FOR SMT 2nd source
CN001 033G8032-6F--L WAFER 6P 1.25MM XIANGLONG
033G8032-6F--X WAFER 6P 1.25MM XINYA 2nd source
033G8032-6F-HR WAFER 6P 1.25MM HR 2nd source
R002,R005 061G0603101-JT
RST CHIPR 100 OHM +-5% 1/10W 0603
TZAI YUAN
R004 061G0603102-JT
RST CHIPR 1 KOHM +-5% 1/10W 0603
TZAI YUAN
R001,R003 061G0603202-JT
RST CHIPR 2 KOHM +-5% 1/10W 0603
TZAI YUAN
LED001 081G--15502-GP LED GPTD12048YGC1 GP
E715 715G5768K0B000004K
Key PCB FR4 DS 105*12*1.6MM 18 联
板 景旺
715G5768K0B000004I
Key PCB FR4 DS 105*12*1.6MM 18 联
板 兴达
2nd source
715G5768K0B000004S
Key PCB FR4 DS 105*12*1.6MM 18 联
板 三照
2nd source
P15G8299--3 Vesa bkt
PLPCCB441XAN4 POWER BOARD
U902 056G-139--9
IC PHOTO COUPLER EL817M(X)
DIP-4 EVERLIGHT
056G-139-3A
IC PHOTO COUPLER PC123Y22FZ0F
SHARP
2nd source
TR901 061G--5810T
RST NTCR 8 OHM +-20% 4A 13mm
THINKING
C908 063G107K474-6S CAP X2 0.47UF K 275VAC
063G107K474-UM CAP X2 470NF 10% 275VAC MPX 2nd source
C902,C903 065G306M1023BW
CAP Y1 1000PF 20% 250VAC Y5U
WANSHENG
065G306M1022BP NO-SUGGEST 1000PF Y1.CAP 2nd source
C900 065G306M3323BW
CAP Y1 3.3nF +-20% 250V Y5U
WANSHENG
C910 067G-40Z12115H2010 EC 120uF 20% 450V 20*40mm
L902 073G-174241--X LINE FILTER 18mH MIN EF20

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
