Page #64 background imageLoading...
Page #64 background image
64
3LFEF2022-303M ASET
073G-174241-CP LINE FILTER 18MH MIN L050234-6 2nd source
L906,L907,L908 073G-253191--H IND CHOKE 1.1uH DADON
073G-253191--L CHOKE COIL 1.1uH CC-007802 LI TAI 2nd source
L801 073G-253214-DN
CHOKE COIL 47UH 10%
LZ.CC013.G01
073G-253214--H
CHOKE COIL 47uH -10% L470R HA
DADON
2nd source
T901 080GL22T--3-H6
X'FMR 490UH 7% 4UH ER28
BCK-12866-HA DADON
S80GL22T3V6 X'FMR 490UH 7% 4UH EER28 TPV-PT 2nd source
CN901 087G-501-48--S AC SOCKET 3PIN+3 Hole SOLTEAM
087G-501-48-DL AC SOCKET 3PIN 3 Hole DLK 2nd source
BD901 093G--50460-44
DIODIE BRIDGE GBL408 4A/800V GBL
LITEON
D901,D902 093G--60335
DIODE SCHOTTKY SR515 5A/150V
DO-201AD TSC
093G--60325
DIODE SCHOTTKY SB5150 5A 150V
DO-201AD LITEON
2nd source
D801A 093G--60520
DIODE SCHOTTKY SR5100-MK23
5A/100V DO-27 SECOS
705GQB57051 Q901 ASS""Y
Q901 057G-667941
MOSFET P0765ATF 7A/650V TO-220F
NIKO-SEM
057G-724-11
MOSFET STP9NK65ZFP 6.4A/650V
TO-220FP ST
2nd source
HS1 090G6064--1 HEAT SINK
0M1G-930--8120 SCREW
705GQC93083 D906 ASS'Y
005G--42--1 WASHER
012G-372--1 thermal pad
HS2 090G6064--1 HEAT SINK
D906 093G--60969
DIODE RECTIFIER MBR30L60CT C0
30A 60V TO220-AB TSC
093G--60970
DIODE RECTIFIER SBL30L60CT 30A
60V TO-220AB LITEON
2nd source
0M1G-930--8120 SCREW
709G4744-QM001 COMSUPTIVE ASS'Y
051G-200--1 OIL FOR DISAPPEAR
052G---2191--A PAPER TAPE
055G--23520 IPA
