AOC I2369Vm Service Manual

65
055G--23524--A
WELDING FULX WITHOUT Pb 无锡助
焊剂
Q49G--51100
唯特偶 GW2066 水基型清洁剂 Cleaner
Q51G---6--4509 GLUE_RTV
Q55G-100622 TIN STICK(SAC0507)
Q55G-100625 TIN STICK_LOW ARGENTUM
CN903 F95G-820-4D208
WIRE HARNESS 4P-4P 130MM
GREATLAND
F95G-820-4T208 WIRE HARNESS 4P-4P 130MM DIY 2nd source
F95G-820-4X208 WIRE HARNESS 4P-4P 130MM XINYA 2nd source
CN902 F95G-825-9D602
WIRE HARNESS 9P-9P 100mm
GREATLAND
F95G-825-9R602
WIRE HARNESS 9P-9P 100mm
DERUN
2nd source
F95G-825-9X602
WIRE HARNESS 9P-9P 100mm
XINYA
2nd source
H40G-45762429A CBCP Label for EE
CN806 LNPCBC123QD1 CONVERSION BOARD
CN801 311GB254A05AAL WAFER 5P 2.54MM XIANGLONG
311GB254A05AAF WAFER 5P 2.54MM JUNFENG 2nd source
709G4033-QM001 COMSUPTIVE ASS'Y
052G---2191--A PAPER TAPE
055G--23520 IPA
055G--23524 WELDING FLUX WITHOUT PB
055G--23524--A
WELDING FULX WITHOUT Pb 无锡助
焊剂
Q49G--51100
唯特偶 GW2066 水基型清洁剂 Cleaner
Q51G---6--4509 GLUE_RTV
Q55G-100622 TIN STICK(SAC0507)
Q55G-100625 TIN STICK_LOW ARGENTUM
LNPC01 LNBC123QD1SMT CONVERSION BOARD FOR SMT
LNBC123QD1SMTWB CONVERSION BOARD FOR SMT WB 2nd source
CN802 311GF050B10ADL FFC CONN 10P 0.5MM XIANGLONG
033G801910Y--H
NO-SUGGEST WAFER 10P 0.5MM
GAOLIN
2nd source
311GF050B10ADH FFC CONN 10P 0.5MM HR 2nd source
E715 715G4033P01000004I
Power board FR-4 DS 20*20*1.6mm
42 连扳 兴达
715G4033P01000004L
Power board FR-4 DS 20*20*1.6mm
42 连扳 威尔高
2nd source
715G4033P01000004S Power board FR-4 DS 20*20*1.6mm 2nd source

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
