AOC I2369Vm Service Manual

66
42 连扳 三照
PLCB441XAN4SMT POWER BOARD FOR SMT
U901 056G-379529
IC AC/DC CONVERTER LD7576AGR
SOP-7 LEADTREND
Q801 057G-763141
MOSFET APM1105NUC-TRG 16A/100V
TO-252-3 ANPEC
RJ609 061G0603000-JF
RST CHIPR MAX 0R05 1/10W
FENGHUA
061G0603000-JT
RST CHIP MAX 0R05 1/10W TZAI
YUAN
2nd source
RJ801 061G0805000-JF
RST CHIPR 0 OHM +-5% 1/8W
FENGHUA
061G0805000-JT
RST CHIPR 0 OHM - 5% 1/8W TZAI
YUAN
2nd source
R818 061G0805000-JT
RST CHIPR 0 OHM +- 5% 1/8W TZAI
YUAN
R804,R808 061G0805100-JF
RST CHIPR 10 OHM +-5% 1/8W
FENGHUA
061G0805100-JT RST CHIP 10R 1/8W 5% TZAI YUAN 2nd source
R907,R928 061G0805102-JF
RST CHIPR 1K OHM +-5% 1/8W
FENGHUA
061G0805102-JT
RST CHIPR 1K OHM - 5% 1/8W
TZAI YUAN
2nd source
R801,R918,R920 061G0805103-JF
RST CHIPR 10K OHM +-5% 1/8W
FENGHUA
061G0805103-JT
RST CHIPR 10 KOHM -5% 1/8W 0805
TZAI YUAN
2nd source
R805 061G0805104-JF
RST CHIPR 100KOHM +-5% 1/8W
FENGHUA
061G0805104-JT
RST CHIPR 100KOHM - 5% 1/8W
TZAI YUAN
2nd source
R824 061G0805150-JY RST 0805 15OHM 1/8W YAGEO
061G0805150-JT RST 0805 15OHM 1/8W 5% TZAI YUAN 2nd source
R815 061G08051623FF RST 0805 162K 1% 1/8W FENGHUA
061G08051623FT RST 0805 162K 1% 1/8W TZAI YUAN 2nd source
R916,R935 061G08052002FF
RST CHIPR 20 KOHM +-1% 1/8W 0805
FENGHUA
061G08052002FT
RST CHIPR 20 KOHM -1% 1/8W 0805
TZAI YUAN
2nd source
R809 061G08052203FF
RST 0805 220KOHM 1% 1/8W
FENGHUA

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
