AOC I2369Vm Service Manual

49
No. Description P/N QTY
1 Bezel A34G3135-OPA1B0130 1
2 Power_lens A33G1429--1-1C0100 1
3 Key_button A33G1437AED-1B0100 1
4 Middle_frame A34G3136AED-1B0100 1
5 mylar_btm Q52G1801MNT176 1
6 mylar_top Q52G1801MNT177 1
7 Main_frame Q15G1351301 1
8 Hinge_bkt Q15G1405101 1
9 Rear_cover A34G3137AED-3B0130 1
10 Stand_front A34G3139AED-1B0100 1
11 Hinge Q37G0307011 1
12 Stand_rear A33G1490AED-1B0100 1
13 Hinge_cover A34G3138AED-1B0100 1
14 Base A34G3141-OP-1B0130 1
15 Base_bkt Q15G1406101 1
16 FOOT PAD Q12G6082--1 5
S1 MAIN FRAME TO PANEL(BACK SIDE) 0M1G3030--4120 1
S2 SCALER TO MAINFRAME(1A2H1DP) 0D1G1030--6120 2
S3 POWER TO MIANFRAME 0D1G1030--6120 2
S4 POWER TO MIANFRAME 0M1G1140--6120 1
S5 MIDDLE FRAME TO PANEL 0M1G3030--4120 8
S6 HINGE TO REAR COVER AM1G1740-10225-CR3 4
S7 REAR COVER TO MAIN FRAME 0M1G3030--4120 2
S8 BKT BASE TO BASE 0Q1G-930--8120 2
S9 HAND SCREW Q01G700100A003 1
S10 REAR COVER TO PANEL 0Q1G-930--8120 1

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
