HP L1740
4
1. Monitor Specifications
Items Descriptions
Driving system TFT Color LCD
Panel CLAA170EA07Q
Size 337.920(H) x 270.336(V) (17.0")
Pixel pitch 0.264mm( W )x 0.264mm( H )
Viewable angle 120/140
Response time (typ.) < 16 ms
Brightness (MIN) 200 nits
Contrast Ratio (MIN) 250/1
LCD Panel
Video Analog /Digital
Sync. Type H/V TTL
H-Frequency 30kHz – 83kHz
Input
V-Frequency 56Hz – 76Hz
Display Colors Over 16 million Colors
Pixel Clock 140MHz
Max. Resolution 1280 x 1024
Plug & Play VESA DDC2B
TM
ON ModeGS
≤70W
OFF Mode <1W
Power Consumption
Sleep Mode <2W
Power Source 100~240VAC,47~63Hz
Environmental
Condition
Operating Temp: 5°C to 35°C
Storage Temp.: -20°C to 60°C
Operating Humidity : 20% to 80%
Unpackaged(W*D*H) 373.3mm*256mm*479.5mm
Main Dimensions
Packaged(W*D*H) 454mm*456mm*230mm
Unpackaged 8.0Kg Unit max
Weight (N. W.)
Packaged 9.32Kg Unit max
Operating 0 to 12,000 feet
Altitude
Non-Operating 0 to 40,000 feet
