AOC L22W961 Service Manual

22ƎLCD TV AOC L22W961
56
11. BOM List
E22R2ZNK4WAENN
Location Part No. Description Remark
 050G 600 2 HANDLE1 
 050G 600 3 HANDLE2 
 052G 1185 MIDDLE TAPE 
 052G 1186 SMALL TAPE 
 052G 1211501 ALUMINUM FOIL TAPE 
 052G 1211511 ALUMINUM FOIL TAPE 
 052G 1211516 ALUMINUM TAPE 
 052G 2191 A PAPER TAPE 
 089G176J30N 21 FFC CABLE 30P 200MM P1.0 
 089G402A15N CX POWER CORD 
 098GRABD2NEACR REMOTE CONTROL RC2443801/01 
 0D1G1740 8120 SCREW 
 0M1G1730 8120 SCREW 
 0M1G1730 8120 SCREW 
 0M1G1730 10120 SCREW 42A9930016 
 0Q1G 930 8 47 CR3 SCREW 
 0Q1G 940 12 47 CR3 SCREW 
 0Q1G1840 10120 SCREW 
 705TQ934C12 STAND ASS'Y 
 A37T0104012 HINGE 
 AM1G1740 12 47 CR3 SCREW 
 P34T0285ADT 1L0133 BASE 
 P34T0286ADT 1L0100 STAND 
 Q12G6082 3 FOOT PAD 
 705TQ934C13 REAR COVER ASS'Y 
 P15T8299 1 BKT-VESA 
 P34T0284ADT 1A0130 REAR COVER TV22W 
 P34T0312ADT 1A0100 COVER-REAR-IO 
 705TQ934C46 BEZEL ASS'Y 
 036T 600 18109 NONWOVEN FABRTC 
 P33T0130AFT 1C0100 LENS-IR 
 P33T0132ADT 1L0100 KEY_FUNCTION 
 P34T0282ADT 1L0129 BEZEL TV22W-9C1 
 P34T0283ADTB1L0100 DECO BEZEL-09 AOC 
 Q36T 600 35 2 GP NONWOVEN FABRIC 
 Q52G 3 79 DOUBLE COATED TAPE 55258 
 750TVV216B1121N000 PANEL TPT216B1-L01 C1B FQ TPV 
 756TQ8CB ZK036 MAIN BOARD-CBPFRZ7KQ6 
U201 056G1133 84 AF24BC02-S1 
U404 056T1133935 IC MX25L3205DMI-12G SOP-16 
SMTF-U201 100TAZMCV01K1E MCU ASS'Y-056G1133 84 
SMTF-U404 100TAZVC001KT1 MCU ASS'Y-056T1133935 
 AM1G1740 12 47 CR3 SCREW 
 AM1G1740 12 47 CR3 SCREW 
 040G 45762412B CBPC LABEL 
CN407 033G3802 9B Y CONNECTOR 9P 2.0 
CN409 033G801930F CH JS CONNECTOR 
CN701 033T327812D WAFER 12P PLUG 
