AOC L32W751A Service Manual

32” LCD TV AOC L32W751A
22
3. Input/Output Specification
3.1 RGB Signal input
15 - Pin Color Display Signal Cable
1
Red Video
9
No Pin!
2
Green Video
10
Sync Ground
3
Blue Video
11
Not Used
4
Not Used
12
Serial Data for DDC
5
Ground
13
H-Sync.
6
Red Ground
14
V-Sync.
7
Green Ground
15
Serial Clock for DDC
8
Blue Ground
3.2 Compatible Mode Table
Dots × Lines
Horizontal
Vertical
Sync Polarity
Presence
Screen Mode
Frequency
Frequency
Horizontal
Vertical
Horizontal
Vertical
Normal
FULL
(kHz)
(Hz)
(4:3)
(16:9)
720×400
31.47
70.08
NEG
POS
YES
YES
YES
YES
640×480
31.50
60.00
NEG
NEG
YES
YES
YES
YES
640×480
37.50
75.00
NEG
NEG
YES
YES
YES
YES
640×480
37.86
72.81
NEG
NEG
YES
YES
YES
YES
800×600
37.90
60.32
NEG
NEG
YES
YES
YES
YES
800×600
46.90
75.00
NEG
NEG
YES
YES
YES
YES
800×600
48.08
72.19
NEG
NEG
YES
YES
YES
YES
1024×768
48.40
60.00
YES
YES
YES
YES
YES
YES
1280×768
47.7
60
YES
YES
YES
YES
YES
YES
