AOC L32W751A Service Manual

32” LCD TV AOC L32W751A
86
12. Different Parts List
Diversity of E327MTNB2WA2NN Compared with E327ATNB2WADNN
Location
Part No.
Description
040T 581 26704
SHIPPING LABEL
045T 77 3
PE PACKING
049T 51 1A
ERADICATOR
052T 2191 A
TAPE
095T801414DH24
WIRE HARNESS 14P-12P 80MM
E095
095T8018 3X686
LVDS CABLE 30P-24P 350MM
0D1T 940 6120
SCREW
0D1T 940 6120
SCREW
0M1T6022500
SCREW
E09502
095T8021 3X550
WIRE HARNESS
715T2691 1
KEY BOARD PCB
750TVMM5B1111N
PANEL V315B1-L01 C2 TW CMO
051T 200 1
OIL FOR DISAPPEAR
051T 200 1
OIL FOR DISAPPEAR
051T 200 1
OIL FOR DISAPPEAR
051T 200 1
OIL FOR DISAPPEAR
CBPF7T3BQ9
MAIN BOARD
U204
056T113362AAB6(Checksum:3EF5;V1.42)
EN29LV800BT-70TCP TSOP-48
R441
061T0603000
CHIP 0OHM 1/16W
R6130
061T0603000
CHIP 0OHM 1/16W
R292
061T0603103
CHIP 10KOHM 1/16W
R713
061T0603472
CHIP 4.7KOHM 1/16W
R257
061T0603472
CHIP 4.7KOHM 1/16W
C747
065T0603224 32
MLCC 0603 0.22UF K 50V X7R
C718
065T0805225 12
CHIP 2.2UF 16V X7R 0805
C6113
067T 4122203XT
CAP 85℃ 22UF M 16V XINDECO
D613
093T 60S 19 T
DIODE SSM0160SPT 1A/60V SOD-123
715T2289 2
MAIN BOARD PCB
Q15T0123A03
PCB-BKT
Q15T0125 2
BKT-HOLD-PANEL
Q44TJ01361511A
CARTON
Q45T 76 28NV2 R
PE BAG FOR CLAMP
Diversity of E327MTNB2WA62N Compared with E327ATNB2WADNN
Location
Part No.
Description
019T6014 1
strape clip
044T9003120
CORNER PAPER
050T 600 1 W
WHITE STRAPE
Q07T 8 3 44
compound pallet
Q07T 8 3 45
compound pallet
Q40T 582813 3A
S/N LABEL
Q44T9003 96
Corner paper
Q44TJ013 5EPE
EPE CUSHION
Q44TJ01361515A
CARTON
Q50T 500519
CABLE TIE
040T 581654 3A
CARTON LABEL
Q44T600027V 9A
carton for small material
040T 581 26646
S/N LABEL
Q44T600019S 2A
CARTON FOR TUNER BOARD
