AOC L32W751A Service Manual

32” LCD TV AOC L32W751A
87
050T 500 1
CABLE TIE
095T801414DH24
WIRE HARNESS 14P-12P 80MM
E095
095T8018 3X686
LVDS CABLE 30P-24P 350MM
705TQ7SK038
SKD ASS'Y
Q07T 8 1 11
COMPOUND PALLET
Q15T0125 2
BKT-HOLD-PANEL
Q40T 32061540A
rating label
Q44T600027V 9A
carton for small material
CBPF7T3BQ9
CONVERSION BOARD
Q15T0122 5
PANEL-BKT-L
Q15T0122 6
PANEL-BKT-R
0M1T1730 10128 GP
SCREW
U204
056T113362AAB6(Checksum:3EF5;V1.42)
EN29LV800BT-70TCP TSOP-48
R441
061T0603000
CHIP 0OHM 1/16W
R6130
061T0603000
CHIP 0OHM 1/16W
R292
061T0603103
CHIP 10KOHM 1/16W
R713
061T0603472
CHIP 4.7KOHM 1/16W
R257
061T0603472
CHIP 4.7KOHM 1/16W
C747
065T0603224 32
MLCC 0603 0.22UF K 50V X7R
C718
065T0805225 12
CHIP 2.2UF 16V X7R 0805
C6113
067T 4122203XT
CAP 85℃ 22UF M 16V XINDECO
D613
093T 60S 15 T
DIODE RB160M-60TE25 ROHM
715T2289 2
MAIN BOARD PCB
Diversity of E327MTNL2WMZNN Compared with E327ATNB2WADNN
Location
Part No.
Description
050T 500 1
CABLE TIE
088T 78502 CL
SCART+RCA JAK R/W/Y
089T412A18NIS3
POWER CORD WALL-OUT FOR AUSTRA
095T801414DH24
WIRE HARNESS 14P-12P 80MM
E09501
095T8018 3X686
LVDS CABLE 30P-24P 350MM
0D1T 930 6120
SCREW
E750
750TVMM5B1111N
PANEL V315B1-L01 C2 TW CMO
CBPF7T3BQ9
MAIN BOARD T2289-2-X-X-11-080306
R147
061T0603472
CHIP 4.7KOHM 1/16W
R116
061T0603472
CHIP 4.7KOHM 1/16W
C747
065T0603224 32
MLCC 0603 0.22UF K 50V X7R
C718
065T0805225 12
CHIP 2.2UF 16V X7R 0805
C102
067T 4122203XT
CAP 85℃ 22UF M 16V XINDECO
D613
093T 60S 15 T
DIODE RB160M-60TE25 ROHM
715T2289 2
MAIN BOARD PCB
Q15T0125 2
BKT-HOLD-PANEL
Q40T0002634 1A
C-TICK LABEL
Q44TJ01361521A
32" TV CARTON
R9
061T0603000
RST CHIPR 0 OHM +-5% 1/10W
R4
061T0603103
RST CHIPR 10KOHM +-5% 1/10W
Q41T320161542A
MANUAL
U204
056T113362AAB6(CHECKSUM:3EF5;V1.42)
EN29LV800BT-70TCP TSOP-48
