AOC L32W751A Service Manual

32” LCD TV AOC L32W751A
64
J915
095T 90 23
JUMP WIRE
J916
095T 90 23
JUMP WIRE
J911
095T 90 23
JUMP WIRE
J908
095T 90 23
JUMP WIRE
J913
095T 90 23
JUMP WIRE
J912
095T 90 23
JUMP WIRE
R990
095T 90 23
JUMP WIRE
J938
095T 90 23
JUMP WIRE
J937
095T 90 23
JUMP WIRE
J936
095T 90 23
JUMP WIRE
J934
095T 90 23
JUMP WIRE
J932
095T 90 23
JUMP WIRE
J931
095T 90 23
JUMP WIRE
J928
095T 90 23
JUMP WIRE
J927
095T 90 23
JUMP WIRE
J926
095T 90 23
JUMP WIRE
J925
095T 90 23
JUMP WIRE
J924
095T 90 23
JUMP WIRE
J923
095T 90 23
JUMP WIRE
J922
095T 90 23
JUMP WIRE
J917
095T 90 23
JUMP WIRE
J907
095T 90 23
JUMP WIRE
715T2463 3
POWER BOARD PCB
CBPF7T3BQ3
CONVERSIONT2289-1-X-X-6-070627
CN601
033T3278 2
WAFER
CN602
033T3278 3
WAFER
CN603
033T3802 5B Y
CONNECTOR
CN203
033T3802 8B Y
CONNECTOR
CN108
033T3802 9B Y
CONNECTOR
CN401
033T8027 24
CONN W TO B 12P*2 P*2.0 4504-2
040T 45762412B
CBPC LABEL
R721
061T152M270 64
27 OHM 5% 2W
R722
061T152M330 64
33 OHM 5% 2W
C667
067T 215471 4
470UF +-20% 25V
C650
067T 215471 4
470UF +-20% 25V
FB702
073T 253137 LS
CHOKE COIL
FB709
073T 253137 LS
CHOKE COIL
L601
073T 253158 H
CHOKE COIL 22UH+/-25%
L602
073T 253158 H
CHOKE COIL 22UH+/-25%
L603
073T 253158 H
CHOKE COIL 22UH+/-25%
L604
073T 253158 H
CHOKE COIL 22UH+/-25%
CN106
088T 78 1331N GP
RCA JACK 1*3P R/B/G
CN105
088T 78 1333N GP
RCA JACK1*2 R/W 5105-845-082-6
CN604
088T 78 1333N GP
RCA JACK1*2 R/W 5105-845-082-6
CN107
088T 30214K
PHONE JACK
CN202
088T 35315F HA
D-SU13 15PIN
CN102
088T 35521L SC
SCART CONN 21PIN SCREW
CN103
088T 35521L SC
SCART CONN 21PIN SCREW
090T 372 2
HEAT SINK
090T6068 2
HEAT SINK
Y401
093T 2253B J
14.31818MHZ/85C
Y201
093T 2264B
27MHZ/30PF/49US
X601
093T 2268B A
CRYSTAL 18.432MHZ/16PF/49U/S ARGO
Y501
093T 2279B
CRYSTAL 28.322MHZ 49U/S
CN104
095T801410X567
WIRE HARNESS
CN701
095T801412X616
WIRE HARNESS
