32’’ LCD TV AOC L32W781A
124
L1
071T 56G301 EA
CHIP BEAD 300 OHM 0805
L22
071T 57G601
BEAD 1206 600 OHM
L21
071T 57G601
BEAD 1206 600 OHM
FL2
071T 57G601
BEAD 1206 600 OHM
FL1
071T 57G601
BEAD 1206 600 OHM
FB1
071T 59B121 K
CHIP BEAD
L14
073T 12622910K
CHIP INDUCTOR 2.2UH 10% 1206
L16
073T 12622910K
CHIP INDUCTOR 2.2UH 10% 1206
L18
073T 12622910K
CHIP INDUCTOR 2.2UH 10% 1206
XD1
093T 22S84B H
CRYSTAL SSP027000I5CH 27.000MHZ H.ELE
715T2271 1
TUNER BOARD PCB
R106
061T0603103
RST CHIPR 10KOHM +-5% 1/10W
R81
061T0603000
RST CHIPR 0 OHM +-5% 1/10W
TUPF7AA2
TUNER BOARD T2296-1-X-X-1-070808
CN3
033T380210B YH
CONNECTOR 10PIN
R1
061T152M270 64
27 OHM 5% 2W
R2
061T152M330 64
33 OHM 5% 2W
TU1
094TPASEALL 3P
FQ1216ME/IH-5(SV22)
U1
056T 585 11
AZ1117D-5.0-E1
R9
061T0603000
RST CHIPR 0 OHM +-5% 1/10W
R6
061T0603101
RST CHIPR 100 OHM +-5% 1/10W
R8
061T0603101
RST CHIPR 100 OHM +-5% 1/10W
R10
061T0603102
RST CHIPR 1KOHM +-5% 1/10W
R4
061T0603103
RST CHIPR 10KOHM +-5% 1/10W
R5
061T0603103
RST CHIPR 10KOHM +-5% 1/10W
C10
065T0603101 31
CHIP 100PF 50V NPO
C8
065T0603104 32
CHIP 0.1UF 50V X7R
C7
065T0603104 32
CHIP 0.1UF 50V X7R
C4
065T0603104 32
CHIP 0.1UF 50V X7R
C3
065T0603104 32
CHIP 0.1UF 50V X7R
C1
067T 4121003XT
EC 85
℃
CHIP 10UF M 16V
C2
067T 4124703XT
EC 85
℃
SMD CAP 47UF M 16V
C5
067T 4124703XT
EC 85
℃
SMD CAP 47UF M 16V
C6
067T 4124703XT
EC 85
℃
SMD CAP 47UF M 16V
L1
071T 56G301 EA
CHIP BEAD 300 OHM 0805
L2
071T 56G301 EA
CHIP BEAD 300 OHM 0805
L3
071T 56G301 EA
CHIP BEAD 300 OHM 0805
715T2296 1
TUNER BOARD PCB
12. Different Parts List
Diversity of E327MTNB2WA1NN compared with E327MTNB2WA52N
Location
Part No.
Description
040T 581 26704
SHIPPING LABEL
Q15T0122 1
PANEL-BKT-L
Q15T0122 2
PANEL-BKT-R
Q40T 32061533A
RATING LABEL
Q40T0001624 4A
PALLET LABEL
Q44TJ01361513A
CARTON
