32’’ LCD TV AOC L32W781A
64
J925 095T 90 23 JUMP WIRE
J924
095T 90 23
JUMP WIRE
J923
095T 90 23
JUMP WIRE
J922
095T 90 23
JUMP WIRE
J917 095T 90 23 JUMP WIRE
J902
095T 90 23
JUMP WIRE
J901
095T 90 23
JUMP WIRE
715T2463 3
POWER BOARD PCB
CBPF7T3BQ9 CONVERSION BOARD T2289-2-X-X-11-070807
CN601
033T3278 2
WAFER
CN602
033T3278 3
WAFER
CN603
033T3802 5B Y
CONNECTOR
CN203 033T3802 8B Y CONNECTOR
CN108
033T3802 9B Y
CONNECTOR
CN401
033T8027 24
CONN W TO B 12P*2 P*2.0 4504-2
040T 45762412B
CBPC LABEL
R721 061T152M270 64 27 OHM 5% 2W
R722
061T152M330 64
33 OHM 5% 2W
C667
067T 215471 4
470UF +-20% 25V
C650
067T 215471 4
470UF +-20% 25V
FB709 073T 253137 LS CHOKE COIL
FB702
073T 253137 LS
CHOKE COIL
L601
073T 253158 H
CHOKE COIL 22UH+/-25%
L602
073T 253158 H
CHOKE COIL 22UH+/-25%
L603 073T 253158 H CHOKE COIL 22UH+/-25%
L604
073T 253158 H
CHOKE COIL 22UH+/-25%
CN106
088T 78 1331N GP
RCA JACK 1*3P R/B/G
CN105
088T 78 1333N GP
RCA JACK1*2 R/W 5105-845-082-6
CN604 088T 78 1333N GP RCA JACK1*2 R/W 5105-845-082-6
CN107
088T 30214K
PHONE JACK
CN202
088T 35315F HA
D-SU13 15PIN
CN102
088T 35521L SC
SCART CONN 21PIN SCREW
CN103 088T 35521L SC SCART CONN 21PIN SCREW
090T 372 2
HEAT SINK
090T6068 2
HEAT SINK
Y401
093T 2253B J
14.31818MHZ/85C
Y201 093T 2264B 27MHZ/30PF/49US
X601
093T 2268B A
CRYSTAL 18.432MHZ/16PF/49U/S ARGO
Y501
093T 2279B
CRYSTAL 28.322MHZ 49U/S
CN104
095T801410X567
WIRE HARNESS
CN701 095T801412X616 WIRE HARNESS
040T 457624 1B
CPU LABEL
U705
056T 133 30AAC
IC AZ1117H-ADJ-E1
U704
056T 133 33AAC
IC AZ1117-1.8-E1
U602 056T 158501 IC AZ431AN-AE1 SOT23-3 AAC
U607
056T 158501
IC AZ431AN-AE1 SOT23-3 AAC
U604
056T 212 5
LM324DT
U710
056T 379 86
IC AP1513SA SOP-8L
U703 056T 563 7 AIC1084-33PM TO-263 AIC
U701
056T 563 34
A1C1084-18PM
U707
056T 56327A
IC AP1117E18LA ANACHIP
