32’’ LCD TV AOC L32W781A
86
715T2478 1 IR BOARD PCB
Q15T0120 11
IO-BKT-TOP
Q15T0122 1
PANEL-BKT-L
Q15T0122 2
PANEL-BKT-R
Q15T0123A03 PCB-BKT
Q15T0125 2
BKT-HOLD-PANEL
Q36T 600 30 2
HIMERON
Q44T3231 21 27
EVA WASHER
Q44T3231 21 28 EVA WASHER
Q44TJ009 7 1A
U TYPE SHEET FOR MANUAL
Q44TJ013 1
CUSHION EPS 32
Q44TJ013 2
CUSHION EPS 32
Q44TJ013 3 CUSHION EPS 32
Q44TJ013 4
CUSHION EPS 32
Q44TJ013624 1A
CARTON
Q44TJ013BLO001
PAPER SHEET
Q45T 76 28NV2 R PE BAG FOR CLAMP
Q45T 99609 2 R
EPE COVER FOR MONITOR
Q45T 99609 39 R
EPE COVER FOR BASE
Q52T 1185 66
AOC TAPE
Q52T6025 15238 MYLAR
Q85T 583145
GASKET
Q85T0041 1
SHIELD
TUPF7AA2
TUNER BOARDT2296-1-X-X-1-070808
CN3 033T380210B YH CONNECTOR 10PIN
R1
061T152M270 64
27 OHM 5% 2W
R2
061T152M330 64
33 OHM 5% 2W
TU1
094TPASEALL 3P
FQ1216ME/IH-5(SV22)
U1 056T 585 11 AZ1117D-5.0-E1
R9
061T0603000
CHIP 0OHM 1/16W
R6
061T0603101
CHIP 100OHM 1/16W
R8
061T0603101
CHIP 100OHM 1/16W
R10 061T0603102 CHIP 1K OHM 1/16W
R4
061T0603103
CHIP 10KOHM 1/16W
R5
061T0603103
CHIP 10KOHM 1/16W
C10
065T0603101 31
CHIP 100PF 50V NPO
C8 065T0603104 32 CHIP 0.1UF 50V X7R
C7
065T0603104 32
CHIP 0.1UF 50V X7R
C4
065T0603104 32
CHIP 0.1UF 50V X7R
C3
065T0603104 32
CHIP 0.1UF 50V X7R
C1 067T 4121003XT
EC 85℃ CHIP 10UF M 16V
C2
067T 4124703XT
EC 85
℃
SMD CAP 47UF M 16V
C5
067T 4124703XT
EC 85
℃
SMD CAP 47UF M 16V
C6
067T 4124703XT
EC 85
℃
SMD CAP 47UF M 16V
L1 071T 56G301 EA CHIP BEAD 300 OHM 0805
L2
071T 56G301 EA
CHIP BEAD 300 OHM 0805
L3
071T 56G301 EA
CHIP BEAD 300 OHM 0805
715T2296 1
TUNER BOARD PCB
0M1T6022500 SCREW
