AOC L42H861 Service Manual

42″LCD TV AOC L42H861
62
0M1T1730 10120
SCREW
Q90G0099 1
HEAT SINK
705TQ757015
Q901 ASS'Y
Q901
057T 667 52
FET 2SK4100LS-T 7A/650V TO-220FI(LS)
090G6084 1 GP
HEAT SINK
0M1T1730 8120
SCREW
705TQ761020
NR901 ASS'Y
NR901
061T 58050 WL GP
RST NTCR 5 OHM +-15% 5A 13MM THINKING
Q09T 203 8
PIN
705TQ793024
D904/D901 ASS'Y
012T 372 2
SILICON
Q904
057T 667 25
STW20NM60
D901
093T 220 33
DIODE FMXA-1106S
0M1T1730 10120
SCREW
0M1T1730 10120
SCREW
Q90T0097A01
HEAT SINK
705TQ793025
D907 ASS'Y
090G6084 1 GP
HEAT SINK
D907
093T 60298
DIODE SBT15006JST 15A/60V TO-220ML(LS)
0M1T1730 8120
SCREW
705TQ793026
BD901 ASS'Y
BD901
093T 50460 18
D10XB60
0M1T1730 10120
SCREW
Q90T0148 1
HEAT SINK
705TQ793027
D916&D917&D906 ASS'Y
D906
093T 60298
DIODE SBT15006JST 15A/60V TO-220ML(LS)
D917
093T 60306
DIODE FMEN-230A 30A/100V TO-220
D916
093T 60306
DIODE FMEN-230A 30A/100V TO-220
0M1T1730 10120
SCREW
Q90T0148 1
HEAT SINK
IC902
056T 379 79
IC LD7522PS SOP-8
IC901
056T 379104
IC ICE2PCS02G PG-DSO-8
IC903
056T 665 10 1
IC RESONANT L6599DTR SO-16N ST
Q908
057T 417 12 T
TRA 2N3904S-RTK/PS SOT-23 KEC
Q907
057T 417 12 T
TRA 2N3904S-RTK/PS SOT-23 KEC
Q906
057T 417 12 T
TRA 2N3904S-RTK/PS SOT-23 KEC
R932
061G0805244
RST CHIPR 240 KOHM +-5% 1/8W
R931
061G1206105
1M 1206
R930
061G1206105
1M 1206
R929
061G1206105
1M 1206
R935
061G1206154
RST CHIPR 150K OHM +-5% 1/4W
R934
061G1206154
RST CHIPR 150K OHM +-5% 1/4W
R933
061G1206154
RST CHIPR 150K OHM +-5% 1/4W
R905
061G1206225
RST CHIPR 2.2 MOHM +-5% 1/4W
R906
061G1206225
RST CHIPR 2.2 MOHM +-5% 1/4W
R920
061G1206225
RST CHIPR 2.2 MOHM +-5% 1/4W
R916
061G1206430 3F
RST CHIPR 430 KOHM +-1% 1/4W
R918
061G1206430 3F
RST CHIPR 430 KOHM +-1% 1/4W
R982
061G1206430 3F
RST CHIPR 430 KOHM +-1% 1/4W
R980
061T0805000
RST CHIPR 0 OHM +-5% 1/8W
R961
061T0805100 2F
RST CHIPR 10 KOHM +-1% 1/8W
R973
061T0805100 2F
RST CHIPR 10 KOHM +-1% 1/8W
R919
061T0805100 2F
RST CHIPR 10 KOHM +-1% 1/8W
R944
061T0805101
RST CHIPR 100 OHM +-5% 1/8W
R964
061T0805101
RST CHIPR 100 OHM +-5% 1/8W
R921
061T0805102
RST CHIPR 1KOHM +-5% 1/4W
R943
061T0805102
RST CHIPR 1KOHM +-5% 1/4W

AOC L42H861 Specifications

General

3D	No
Power LED	Yes
Pixel pitch	0.4845 x 0.4845 mm
Vertical scan range	60 - 75 Hz
Headphone connectivity	3.5 mm
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	31.5 - 60 kHz
Response time	8 ms
Display diagonal	42 \
Display brightness	500 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (dynamic)	6000:1
Contrast ratio (typical)	1500:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	176 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
Package depth	251.46 mm
Package width	1155.7 mm
Package height	807.72 mm
Package weight	25600 g
Certification	FCC, cULus, RoHS, TUV-S
Audio (L/R) out	1
SCART ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	2
Sustainability certificates	ENERGY STAR
Product color	Black
LED indicators	Y, Stand-by
Panel mounting interface	400 x 200 mm
Cables included	AC, VGA
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
RMS rated power	14 W
Tuner type	Analog
Analog signal format system	NTSC, PAL, PAL M, PAL N

Weight and Dimensions

Depth (with stand)	261.62 mm
Width (with stand)	1010.92 mm
Height (with stand)	688.34 mm
Depth (without stand)	99.06 mm
Height (without stand)	635 mm
