AOC L42H861 Service Manual

42″LCD TV AOC L42H861
73
R280
061T0603750 9F
CHIP 75OHM 1/10W 1%
R281
061T0603750 9F
CHIP 75OHM 1/10W 1%
R2C5
061T0603750 9F
CHIP 75OHM 1/10W 1%
R2C6
061T0603750 9F
CHIP 75OHM 1/10W 1%
R2C7
061T0603750 9F
CHIP 75OHM 1/10W 1%
R2C8
061T0603750 9F
CHIP 75OHM 1/10W 1%
R2C9
061T0603750 9F
CHIP 75OHM 1/10W 1%
R506
061T0603821
RST CHIPR 820 OHM +-5% 1/10W
R692
061T0603821
RST CHIPR 820 OHM +-5% 1/10W
R463
061T0603821
RST CHIPR 820 OHM +-5% 1/10W
R4B1
061T0603822
RST CHIPR 8.2 KOHM +-5% 1/10W
R446
061T0603845 0F
RST CHIPR 0603 845R 1/10W 1%
R447
061T0603845 0F
RST CHIPR 0603 845R 1/10W 1%
FB401
061T0805479
RST CHIPR 4.7 OHM +-5% 1/8W
R720
061T0805560 1F
RST CHIPR 5.6 KOHM +-1% 1/8W
R466
061T1206000
RST CHIPR 0 OHM +-5% 1/4W
R738
061T1206000 4
RST CHIPR 0 OHM +-5% 1/4W
R739
061T1206000 4
RST CHIPR 0 OHM +-5% 1/4W
R740
061T1206000 4
RST CHIPR 0 OHM +-5% 1/4W
R653
061T1206220
RST CHIPR 22 OHM +-5% 1/4W
R633
061T1206220
RST CHIPR 22 OHM +-5% 1/4W
C466
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C467
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C468
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C469
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C470
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C471
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C472
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C473
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C474
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C475
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C465
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C411
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C413
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C414
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C451
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C453
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C455
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C456
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C458
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C459
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C460
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C463
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C464
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C495
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C496
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C497
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C498
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C499
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C4A1
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C4A2
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C4A3
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C4A4
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C4A5
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C4C9
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C4D2
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R
C494
065T0402104 12
CAP CHIP 0402 0.1UF 16V X7R

AOC L42H861 Specifications

General

3D	No
Power LED	Yes
Pixel pitch	0.4845 x 0.4845 mm
Vertical scan range	60 - 75 Hz
Headphone connectivity	3.5 mm
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	31.5 - 60 kHz
Response time	8 ms
Display diagonal	42 \
Display brightness	500 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (dynamic)	6000:1
Contrast ratio (typical)	1500:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	176 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
Package depth	251.46 mm
Package width	1155.7 mm
Package height	807.72 mm
Package weight	25600 g
Certification	FCC, cULus, RoHS, TUV-S
Audio (L/R) out	1
SCART ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	2
Sustainability certificates	ENERGY STAR
Product color	Black
LED indicators	Y, Stand-by
Panel mounting interface	400 x 200 mm
Cables included	AC, VGA
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
RMS rated power	14 W
Tuner type	Analog
Analog signal format system	NTSC, PAL, PAL M, PAL N

Weight and Dimensions

Depth (with stand)	261.62 mm
Width (with stand)	1010.92 mm
Height (with stand)	688.34 mm
Depth (without stand)	99.06 mm
Height (without stand)	635 mm
