18
CONNECTING EQUIPMENT
Coaxial (RF)
Using Your Antenna or Digital Cable for DTV
1. Turn off the power to the HDTV.
2. Connect the coaxial (RF) connector from your antenna or digital cable
(out-of-the-wall, not from the Cable Box) to the ANTENNA/CABLE
DIGITAL/ANALOG connector.
3. Turn on the power to the HDTV.
4. Select DTV using the INPUT button on the remote, side of the HDTV or
directly by pressing the TV button on the Remote Control.
Using Your Antenna or Cable for TV
1. Turn off the power to the HDTV.
2. Connect the coaxial (RF) connector from your antenna or cable (out-of-
the-wall, not from the Cable Box) to the ANTENNA/CABLE
DIGITAL/ANALOG connector at the rear of the HDTV
3. Turn on the power to the HDTV.
4. Select TV using the INPUT button on the remote, side of the HDTV or
directly by pressing the TV button on the Remote Control.
