AOC LE32H1461/20 - Page 60

60
R679
5.1K 1%
R657
10K +-1% 1/16W
R658
4.7K 1/16W
R659
2.2K 1%
R668
470R 1/16W 5%
C678
10UF 6.3V 20%
D601
BAV70
3
1
2
Q603
LMBT3904LT1G
D602
BAS316
R660
4.7K 1/16W
HP_AC_MUTE
R664
1K 1/16W 1%
C680
100NF 16V
C679
NC/10UF 6.3V 20%
Q601
LMBT3904LT1G
R669
10K +-1% 1/16W
DVDD3V3
DVDD3V3
+5V_SW
DVDD3V33,4,5,6,8,10,11,13,15,16,17,18
+5VSB
DVDD3V3
+5V_SW3,10,11,12,15
HP_AC_MUTE6
HP_MUTE10
+5VSB3,7,16
GND3,4,5,6,7,8,10,11,12,13,14,15,16,17,18
+5VSB
+5V_SW
C677
NC 100N 16V
R656
NC 33R 1/16W 5%
CN603
NC CONNNECTOR
GND
1
VCC
2
VIN
3
+5V_SW
SPDIF_OUT5
15mil
OPTICAL
SPDIF_OUT
R624
100R 1/16W 5%
CO-LAY
C685
100NF 16V
R654
180R 1/16W 5%
CN604 RCA JACK
1
2
C686
33P 50V
COAXIAL
ZD602
AZ5123-01H
12
HP_MUTE
A_MUTE
HP_MUTE
AC OFF
DC OFF
Audio Mute for SCART
HP_MUTE
H: MUTE
L: UN-MUTE
10mil
10mil
SPDIF OUT
SPDIF_OUT
Mute Control
GPIO Control Mute
A_MUTE
+
C681
22uF 16V
HP_AC_MUTE
