87
11. BOM List
Note: The following information of initial version BOM are only for reference of repair, not place the order as the
basis and are subject to change without notice. Please base on RSPL or Service BOM (http://cs.tpv.com.cn),
thank you!
E32F92NSKJB13NX
Location Part No. Description Remark
905TXEBC320AF300CX 905 ASS’Y FOR BRAZIL PCBA
756TXFCB02S030020X MAIN BOARD-CBPFF7PSX111CX
SMTF-U405 100TA2VK001S2X MCU ASSY-356G3333001603
SMTF-U406 100TA2VK002S1X MCU ASSY-056G1133174
CN604 088G 78F111VCL RCA JACK V/T 2P BLACK 1*1 H=8.6
CN604 088G 78F111VYG RCA JACK V/T 2P BLACK 1*1 H=8.6
CN102 088G 78G132ACL RCA JACK R/A 7P Y/W/R 1*3 H=10.5
CN102 088G 78G132AYG RCA JACK R/A 7P Y/W/R 1*3 H=10.5
CN602 088G302G7B1ACL PHONE JACK R/A 7P BLACK H=10.5
CN602 088G302G7B1AYG PHONE JACK R/A 7P BLACK 10.5MM
CN601 311GW200A04ABX WAFER 2.0MM 4P
CN701 311GW200C12BBL CONN 2.0MM 12P R/A B2000W12HTKE
CN408 311GW200C30ABL WAFER 2.0MM 2*15P
CN402 311GW200G03BAL WAFER 2.0MM 3P V/T B2019W03VT00
CN103 388G352F6B3AXH00HF USB A TYPE 319AFKD21BNHF 6P 1*1 BLACK
FCN101 388G510F504VCL RF V/T 5P 1*1 BLACK 8.5MM
709T68360XM00C COMSUMPTIVE ASSY
055G 23524 WELDING FLUX WITHOUT PB
Q49G 51100 CLEANER
Q55G 100620500 TIN STICK(SN-0.5AG)
CN406 033G8032 7F S J CONN 1.25MM 7P V/T 7.5MM 2.6MM
U103 056G 563156 IC G9141T11U SOT23-5
ZD106 056G 662 41 ESD PROTECT AZ5123-01H.R7G (FOR 3.3V CI
ZD602 056G 662 41 ESD PROTECT AZ5123-01H.R7G (FOR 3.3V CI
ZD108 056G 662 41 ESD PROTECT AZ5123-01H.R7G (FOR 3.3V CI
ZD107 056G 662 41 ESD PROTECT AZ5123-01H.R7G (FOR 3.3V CI
ZD501 056G 662 41 ESD PROTECT AZ5123-01H.R7G (FOR 3.3V CI
ZD518 056G 662 41 ESD PROTECT AZ5123-01H.R7G (FOR 3.3V CI
ZD118 056G 662 41 ESD PROTECT AZ5123-01H.R7G (FOR 3.3V CI
ZD119 056G 662 41 ESD PROTECT AZ5123-01H.R7G (FOR 3.3V CI
U406 056G1133174 EEPROM M24128-BRMN6TP 128 KB SO8
U410 056G74LS 4 IC 74CBTLV1G125GW SOT353-1
Q707 057G 417511 MMBT3904
Q705 057G 417511 MMBT3904
Q703 057G 417518 TRA LMBT3904LT1G 200MA/40V SOT-23 LRC
Q402 057G 417518 TRA LMBT3904LT1G 200MA/40V SOT-23 LRC
Q603 057G 417518 TRA LMBT3904LT1G 200MA/40V SOT-23 LRC
Q601 057G 417518 TRA LMBT3904LT1G 200MA/40V SOT-23 LRC
Q708 057G 761516 SMALLTRAN BC847C 0.1 50 SOT-23
Q503 057G 761516 SMALLTRAN BC847C 0.1 50 SOT-23
Q506 057G 761516 SMALLTRAN BC847C 0.1 50 SOT-23
Q502 057G 761516 SMALLTRAN BC847C 0.1 50 SOT-23
Q504 057G 761516 SMALLTRAN BC847C 0.1 50 SOT-23
Q401 057G 763 79 FET AO4449 -7A/-30V SOIC-8
Q701 057G 763940 MOSFET AO3401A SOT-23
RP101 061G 1253308JF RST CHIP AR 8P4R 33 OHM +-5% 1/16W
TH101 061G 56A075 LT HF SMD PTC 0.75A 1206L075THYR
R152 061G0402000 JT RST 0402 0.05R MAX 1/16W -
R480 061G0402000 JT RST 0402 0.05R MAX 1/16W -
R104 061G0402000 JT RST 0402 0.05R MAX 1/16W -
To Next Page
