AOC LE32H1461/20 - Page 80

80
715G7381R01000004K (43”&49”)
R204
100R 1/10W 5%
R0603
R205
NC 10K 1%
033G8032 5F S HR
R206
NC 10K 1%
VCC
VCC
U201
IRM-H938M3/TR2
GND
1
GND
2
OUT
3
VCC
4
IR
VCC
R201
15K 1/10W
LED_B
081G 14 24 EL
R203 220 OHM 1/10W
RED
BLUE
LED201
LED
1
23
4
R202 220 OHM 1/10W
LED_R
CN201
CONN
1
2
3
4
5
67
356GS927057
C201
2.2UF 16V
