7. Adjustment
7.1 White Balance Adjustment
It only need adjust WB(Ypbpr
’s Normal/Warm/Cool).
Content of WB Adjustment
1. Enter into the factory mode:MENU+1+9+9+9+back
2. Take an example of adjust Ypbpr_Normal:
a. Select item “Source”: Ypbpr and item “Color Temp”: Normal.
b. Adjust gain of RGB to meet spec in the below setting of tim\pat.
(COMPONENT mode: TIM = 314; PAT = 141(80IRE))
3. Check the colour temperature of other “Source”,If the colour temperature can’t meet spec,please adjust it
4. The white color temperature should be app.
Normal/(9300
K) Warm/(6500K) Cool/(12000K)
x (center) 0.285 0.003 0.313 0.03 0.271 0.003
y (center) 0.293 0.003 0.329 0.003 0.274 0.003
Lv(center) >200cd >200cd >200cd
