AOC LE40D3142 Service Manual

45
9.3 IR Board
715G6077R01000004K
R204
100R 1/10W 5%
R0603
VCC
9mm
35mm
1
2
3
4
5
67
CN201
CON201
GND
1
GND
2
OUT
3
VCC
4
U201
IRM-H938M3/TR2
IR
VCC
R201
15K 1/10W
081G 14 24 EL
OEM MODEL Size
Rev
Date
Sheet of
TPV MODEL
PCB NAME
称爹
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
絬 隔 瓜 絪 腹
A
A
22Thursday , January 17, 2013
<
称爹 >
02-IR&LED
R203 220 OHM 1/10W
LED_B
LED_R
1
23
4
RED
BLUE
LED201
LED
R202 220 OHM 1/10W
356GS927057
311GW125D05ACX
C201
2.2UF 16V
