11. BOM List
Note: The following information of initial version BOM are only for reference of repair, not place the order as the
basis and are subject to change without notice. Please base on RSPL or Service BOM (
http://cs.tpv.com.cn),
thank you!
E40E21NSDNE6NNX
Location Part No. Description Remark
0M1G 130 6 47 CR3 SCREW 3X6
0M1G1730 6120 SCREW 3X6
0M1G1730 8 47 CR3 SCREW
0M1G1730 8120 SCREW
0M1G1740 8120 SCREW FOR STD/MF 42-D020715/42-D000649()
0M1G1740 12 47 CR3 SCREW 12X4
0Q1G 130 5120 SCREW
0Q1G 130 6120 XL SCREW 3X6
0Q1G 930 6 47 CR3 SCREW 3X6
SP01 378G0110567CDN 6 OHM 11W 146X34X41.9MM 0 UNIT
392GB1JA1A3E2C BATTERY 1.5V 2P LR03(KA)2S/G
ECN601 395G801404RD19 HARNESS 4P PITCH2.0-B&R+B&W 550+280MM
ECN401 395G801410DC32 HARNESS 10P PITCH2.0-5P PITCH1.25+2P PI
ECN701 395G801416DC61 HARNESS 16P PITCH2.0-12P PITCH2.0 450MM
ECN408 395G801851XD02 LVDS CABLE 30P-51P 450MM
RC01 398GRABD7NEACR REMOTE AOC RC2414704/01 ENGLISH
708GMA410CPX01 EPI 40(504 SA)
052G 1185 1 BIG TAPE(Y1200141)
Q45G 77511 PROTECT BAG
Q50G 4 10 TIE (Y1900221)
E750 750TBV400J61P8N000 LCD PANEL TPT400LA-J6PE1 SC1P XM TPV XM 2nd-source
756TXECB01S003000X MAIN BOARD-CBPFDMESA2
SMTF-U403 100TAMVT009STX MCU ASSY-356G2233073
Z40G0002ALL01A OTHER LABEL
C778 067G 5154713LV EC 470UF 20% 16V 8*9 6000 HR
C602 067G 5154713LV EC 470UF 20% 16V 8*9 6000 HR
CN111 088G 78G155ACL RCA JACK R/A 13P G/BL/R/W/R 1*5 H=10.5
CN102 088G302G3G2ACL PHONE JACK R/A 3P GREEN H=10MM
CN602 088G302G7B1ACL PHONE JACK R/A 7P BLACK H=10.5
CN103 088G352F6B3AYG USB CONN A TYPE R/A 6P BLACK H=8.4
CN101 088G353GFF1AXH D-SUB CONN 15P BLUE - R/A 10
CN601 311GW200A04ABL CONN 2.0MM 4P R/A B2009W04HTK0
CN401 311GW200C10AAL WAFER 2.0MM 10P
CN701 311GW200C12BBX CONN 2.0MM 12P R/A W2010-12RVA-S04
CN408 311GW200C30AAL00HF WAFER 2.0MM 30P V/T B2000W30VTKB-HF
CN604 388G078G111ACL RCA R/A 3P 1*1 ORANGE 10.5
FCN101 388G510F501AHC RF R/A 5P 1*1 - 9.3MM
709T66890XM001 COMSUMPTIVE ASSY
055G 23524 WELDING FLUX WITHOUT PB
Q49G 51100 CLEANER
Q55G 100625 TIN STICK_LOW ARGENTUM
HS601 Q90G0198 1 HEAT SINK
U706 056G 563153 HF LDO AP1117DG-13 1A ADJ TO252-3L
U705 056G 563344 DC/DC AT1529F11U 3.2A SOP-8
U701 056G 585 4A LDO AP1117E33G-13 1A 3.3V SOT-223
U101 056G 585 4A LDO AP1117E33G-13 1A 3.3V SOT-223
U410 056G 643 5B IC G690H293T73UF SOT-23 GMT
To Next Page
