AOC LE40D3142 Service Manual

67
E40E21NSDNE79NX
Location Part No. Description Remark
052G 1185 1 BIG TAPE(Y1200141)
E38901 089G202A15N IS AC POWER CORD 1500 FOR AMERICA
0M1G 130 6 47 CR3 SCREW 3X6
0M1G1730 6120 SCREW 3X6
0M1G1730 8 47 CR3 SCREW
0M1G1730 8120 SCREW
SP01 378G0110567CDN 6 OHM 11W 146X34X41.9MM 0 UNIT
392GB1JA1A3E2C BATTERY 1.5V 2P LR03(KA)2S/G
ECN601 395G801404RD19 HARNESS 4P PITCH2.0-B&R+B&W 550+280MM
RC01 398GRABD7NEACR REMOTE AOC RC2414704/01 ENGLISH
705TXE4134300X DFU ASS'Y
Q45G2010M0101A PE BAG FOR MANUAL
X41G40MV67303B MANUAL LE40D3142 SA
X41G78DV67311A SHEET-FLYER SERVICE CENTER LIST MEXICO
X41G78DV67312A WARRANTY CARD MEXICO SKD2
X41G78SV67328A QSG LE40D3142/30 SA
040G 58162435A MANUAL P/N LABEL
705TXEMK33500X SCREW ASS'Y
0M1G1740 12225 CR3 SCREW M1-MACHINE SCREW X12.0
Q45G88010TV08900X1 PROTECT BAG
X40G0001624 2A LABEL FOR SCREW PE BAG
705TXEMK34300X SCREW ASS'Y
0M1G1740 12 47 CR3 SCREW 12X4
Q45G88010TV08900X1 PROTECT BAG
X40G0001624 2A LABEL FOR SCREW PE BAG
705TXES234400X SKD2 ASS'Y
052G 1185 1 BIG TAPE(Y1200141)
0M1G1740 8120 SCREW FOR STD/MF 42-D020715/42-D000649()
0Q1G 130 5120 SCREW
0Q1G 930 6 47 CR3 SCREW 3X6
ECN401 395G801410DC32 HARNESS 10P PITCH2.0-5P PITCH1.25+2P PI
ECN701 395G801416DC61 HARNESS 16P PITCH2.0-12P PITCH2.0 450MM
ECN408 395G801851XD02 LVDS CABLE 30P-51P 450MM
E750 750TBV400J61P8N000 LCD PANEL TPT400LA-J6PE1 SC1P XM TPV XM 2nd-source
IRPFDAAK IR BOARD
R204 061G0603101 JT RST CHIP 100R 1/10W 5% TZAI YUAN
R201 061G0603153 JY RST CHIPR 15KOHM 1/10W YAGEO
R203 061G0603221 JF ST CHIPR 220 OHM +-5% 1/10W FENGHUA
R202 061G0603221 JF ST CHIPR 220 OHM +-5% 1/10W FENGHUA
C201 065G060322515K T CAP 0603 2.2UF 10% 16V X5R
LED201 081G 14 24 EL CHIP LED BLUE/DARK RED
CN201 311GW125D05ACX WAFER 1.25MM 5P V/T S1315-05SVB-S03-R
U201 356GS927057 IR RECEIVER IRM-H938M3/TR2 38 KHZ 6V
E715 715G6077R01000004K IR BOARD PCB
E715 715G6077R01000004S IR BOARD PCB 2nd-source
KEPFDAAM KEY BOARD
Q40G000161520A CARTON LABEL
R02 061G0603000 JF RST CHIPR MAX 0R05 1/10W FENGHUA
R02 061G0603000 JT RST CHIP MAX 0R05 1/10W TZAI YUAN
R01 061G06031201FF RST CHIPR 1.2KOHM +-1% 1/10W
R01 061G06031201FT RST CHIP 1K2 1/10W 1%
R05 061G06031502FF RST CHIPR 15KOHM +-1% 1/10W FENGHUA
