AOC LE40D3142 Service Manual

76
X401 093G 22SX02 J CRYSTAL NXE24.000AE18F-BK8 24M 20PPM 10P
ZD701 093G 39SA09 T ZENER RLZ9V1B 9.01 MAX 0.5 LL-34
ZD120 093G 60S902 T DIODE BAT54 SOT-23 PHILIPS
ZD601 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ
ZD602 093G 64S500 SU ESD MLVG04025R0QV05BP INPAQ
U102 356G0566024600 SILICON TUNER MXL661-AG-R
U401 356G0568156607 SCALER MSD8120PBN-Z1 EPLQFP-156
U601 356G0616048168 AUDIO TAS5729MDDCAR 10W TSSOP-48
U505 356G0667023 POWER SWITCH APL3511CBI-TRG SOT23-5
U403 356G2233073 FLASH W25Q64FVSSIG 64MB SOIC-8
U707 356GD563008139 DC/DC G5759F11U 4A 5V SOP-8(FD)
Q501 357G07630620HF HF MOSFET 2N7002K_R1_00001 0.3A 60V
C614 365G060310535K000T CAP 0603 1UF 10% 50V X5R
C606 365G060310535K000T CAP 0603 1UF 10% 50V X5R
L103 373G0402277FJM CHIP IND 27NH 5% 300MA 0.7OHM MGCI1005T
L105 373G0402277FJM CHIP IND 27NH 5% 300MA 0.7OHM MGCI1005T
L104 373G0402826FJM CHIP IND 8.2NH 5% 0.3A 0.35R MGCI1005T8
L701 373G253S198D00 SMD CHOKE 4.7UH 20% 3.3A 0.026R SWPG604
X102 393G022SA4800J CRYSTAL NXE16.000AC20F-BK6 30 PPM 20PF
709T66890XS001 COMSUMPTIVE ASSY
Q52G170100700B00XW MESH PRINTTING_PAPER
E715 715G6689M0A001004N MAIN BOARD PCB
HS401 X85T804210100000LH SHIELD_MAINBOARD
705TXESP34300X POWER ASS'Y
PLTVDQ311XXRS POWER BOARD
Z40G0002ALL01A OTHER LABEL
CN8101 033G380212B YH WAFER 12P 2.0 DIP
IC9401 056G 139 9 IC EL817M(X) PHOTOCOUPLER DIP-4
IC8102 056G 139 9 IC EL817M(X) PHOTOCOUPLER DIP-4
IC9102 056G 139 9 IC EL817M(X) PHOTOCOUPLER DIP-4
R9808 061G3SWJ70759B SY RST WD 0.07R 5% 3W
C9906 063G107M47410M CAP X2 470NF 20% 275V R46KI3470HAP1M
C9905 063G107M47410M CAP X2 470NF 20% 275V R46KI3470HAP1M
CN9902 087G 50147D HC HF HF AC SOKET R/A 2P 12DEGREE H=12.8
BD9801 093G 50460514 BRIDGE KBP306G-05 3A 800V KBP
0Q1G 340 8140 SCREW Q1-SELF TAPING SCREW :Q X8.0
CN9100 311GW200C16BBX ONN 2.0MM 16P R/A W2010-16RVA-S04,B200
IC8103 356G0700008060 LED DRIVER TPV101D DIP-8
IC8105 356G0700008060 LED DRIVER TPV101D DIP-8
RV9901 361G0046621KZE VARISTOR 620V 10%
RV9901 361G0046621KZW VARISTOR 620V 10%
NR9902 361G0058159MYX008A NTCR 1.5R 20% 3.6W 1.5D2-15MCSF
NR9901 361G0058159MYX008A NTCR 1.5R 20% 3.6W 1.5D2-15MCSF
R9808 361G3SWJ70759B00TZ RST WD 0.07R 5% 3W NKNP3WS0R07JMS10
C9805 363G210J105GHP CAP MPP 1UF 5% 450V
C9815 367G215X470PKZ002S .C 47UF 20% 450V 12.5*36 2000 HR 420MA P
C9814 367G215X470PKZ002S .C 47UF 20% 450V 12.5*36 2000 HR 420MA P
C8108 367G515X121JKZ EC 120UF 20% 100V EV2A121MLT0830F5R
C8107 367G515X121JKZ EC 120UF 20% 100V EV2A121MLT0830F5R
FB9901 371G0055021H02 BEAD 6.5*12.5 700R 25% BF-I60100R-815
FB9902 371G0055021H02 BEAD 6.5*12.5 700R 25% BF-I60100R-815
L9901 373G0174298H00 LINE FILTER 9MH MIN 1.2A --
L9901 373G0174298X00 LINE FILTER 9MH MIN 1.2 3LFEF2022-902M
L9903 373G0174301H00 LINE FILTER 0.25MH MIN 2A LCL-11010 HA
