Item Description

1 DECO

2 BEZEL

3 LENS_IR

4 LENS_LED

5 SPEAKER

6 KEY BOARD

7 IR BOARD

8 PANEL

9 BRACKET_PANEL-HOLDER

10 BRACKET_MAINPCB-LEFT

11 MYLAR

12 MAIN BOARD

Item Part No. Description Qty

13 BRACKET MAINPCB-RIGHT 25 0M1G1760 12225 CR3 SCREW(BASE/BASE BKT) 4

14 AC COVER 26 0M1G 930 8 47 CR3 SCREW(BKT/PANEL) 1

15 BRACKET_IO-DOWN 27 0Q1G 940 12 47 CR3 SCREW(REAR COVER/BEZEL) 4

16 BRACKET IO-SIDE 28 0Q1G 940 10 47 CR3 SCREW(REAR COVER/BEZEL) 11

17 BRACKET HINGE BKT 29 0Q1G 130 8120 SCREW(BASE/BASE BKT) 6

18 REAR COVER 30 0M1G1740 14225 CR3 SCREW(COVER STAND/HINGE) 4

19 BRACKET 31 0M1G1740 12225 CR3 SCREW(COVER STAND/HINGE BKT) 5

20 COVER STAND 32 0M1G1740 10125 SCREW(HINGE BKT/PANEL) 4

21 HINGE 33 0M1G1740 6120 SCREW(POWER BOARD/PANEL) 1

22 STAND NECK 34 0M1G1730 6120 SCREW(MAIN BOARD/PANEL/POWER BOARD) 14

23 BASE 35 0Q1G1030 6120 SCREW(IR BOARD) 1

24 BRACKET_BASE 36 0Q1G 930 6120 SCREW(BEZEL/PANEL) 11
