AOC LE58D3140 Service Manual

53
11. BOM List
Note: The following information of initial version BOM are only for reference of repair, not place the order as the
basis and are subject to change without notice. Please base on RSPL or Service BOM (http://cs.tpv.com.cn
),
thank you!
E58EM1NSESE6NNX
Location Part No. Description Remark
 X52G20010TV03700BK INSULATING SHEET 
 0M1G 130 6 47 CR3 SCREW 3X6 
 0M1G 130 8 47 CR3 SCREW 3X8 
 0M1G 130 10 47 CR3 SCREW 
 0M1G 940 8 47 CR3 SCREW 4X8 
 0M1G 940 8120 SCREW 
 0M1G 940 8120 SCREW 
 0M1G1730 6120 SCREW 3X6 
 0M1G1730 8120 SCREW 
 0M1G1730 8120 SCREW 
 0M1G1740 8120 SCREW FOR STD/MF 42-D020715/42-D000649() 
 0Q1G 930 6 47 CR3 SCREW 3X6 
 0Q1G 930 6 47 CR3 SCREW 3X6 
 0Q1G 930 6 47 CR3 SCREW 3X6 
SP01 378G0110567CDN 6 OHM 11W 146X34X41.9MM 0 UNIT 
ECN01 395G801402RC01 HARNESS 2P PITCH2.0-2P PITCH1.25 200MM 
ECN601 395G801404RD29 HARNESS 4P-2P+2P 950MM/260MM 
ECN401 395G801410RC52 HARNESS 10P PITCH2.0-5P PITCH1.25+2P PI 
ECN8102 395G801412RC19 HARNESS 12P - 12P 800 MM 
ECN9102 395G801414XC41 HARNESS 14P PITCH2.0-14P PITCH2.0 400MM 
ECN701 395G801416DC80 HARNESS 16P PITCH2.0-12P PITCH2.0 750MM 
ECN701 395G801416RC80 HARNESS 16P PITCH2.0-12P PITCH2.0 750MM 2nd-source
ECN408 395G801851LD46 LVDS CABLE 51P-30P 700MM 
ECN408 395G801851RD46 LVDS CABLE 51P-30P 700MM 2nd-source
 398GRABD7NEACR REMOTE AOC RC2414704/01 ENGLISH 
 708GWA110CPX02 AOC 40(176 SA) 
 Q50G 4 10 TIE (Y1900221) 
 052G 1185 1 BIG TAPE(Y1200141) 
 Q45G 77511 PROTECT BAG 
 Q50G060046502A00BL PACKAGE_BUCKLE 
E750 750TBN580J1L23N000 LCD V580HJ1-LD6 C2 NH CMI 
 756TXECB01S006000X MAIN BOARD-CBPFDMESX2 
SMTF-U403 100TAMVW001STX MCU ASSY-356G2233073 
 ADTVE6020XA2 POWER BOARD 
 Z40G0002ALL01A OTHER LABEL 
CN9102 033G380214B YH WAFER 2.0MM 14P W2015-14RVA-S01 
IC9304 056G 139 9 IC EL817M(X) PHOTOCOUPLER DIP-4 
IC9102 056G 139 9 IC EL817M(X) PHOTOCOUPLER DIP-4 
IC9104 056G 139 9 IC EL817M(X) PHOTOCOUPLER DIP-4 
Q9106 057G 667914 MOSFET TK10A50D 10A 500V TO-220 
Q9105 057G 667914 MOSFET TK10A50D 10A 500V TO-220 
R9808 061G153M10859B SY RST MOF 0.1R 5% 3WS PITCH=20MM 
C9906 063G107M47410M CAP X2 470NF 20% 275V R46KI3470HAP1M 
C9905 063G107M47410M CAP X2 470NF 20% 275V R46KI3470HAP1M 
FB9902 071G 55906 FERRITE CORE 510R C8B R6H 6X9.2(A) 
FB9801 071G 55906 FERRITE CORE 510R C8B R6H 6X9.2(A) 
FB9901 071G 55906 FERRITE CORE 510R C8B R6H 6X9.2(A) 
