AOC LM725
6
3. Operating Instructions
3.1 General Instructions
Press the power button to turn the monitor on or off. The other control buttons are located at front panel of the
monitor. By changing these settings, the picture can be adjusted to your personal preferences.
• The power cord should be connected.
• Connect the video cable from the monitor to the video card.
• Press the power button to turn on the monitor position. The power indicator will light up.
3.2 Front Panel Control
- Auto Adjust Key:
The Auto Adjust Key is used to automatically set the H Position, V Position, Clock and Phase.
- Power Indicator:
Green — Power On mode.
Orange — Power Saving mode.
NO. Name Within OSD Without OSD
1 Auto
Exit OSD or back to previous menu Auto configuration
2 VOL- /
1.Move the cursor to left
2. Decrease the value of the selected item
Activate
the volume menu
3 VOL+ /
1.Move the cursor to right
2.Adjust up when menu item selected
Activate
the volume menu
4 MENU
Select Function or select Sub menu Activate OSD main menu
5 Power Power On / Off Power On / Off
6 Indicate light Green—On Orange—Save Green—On Orange—Save
