AOC QDI TFT1780PSA User Manual

17” LCD Color Monitor QDI TFT1780PSA
23
M1G 330 4128 SCREW M3X4
M1G 330 6128 SCREW
M1G1130 6128 SCREW
M1G1140 6128 SCREW 4X6
M1G1740 12128 SCREW
Q1G 340 12128 SCREW
Q1G 340 16128 SCREW 4X16
Q1G1030 10128 SCREW
705L782KB34079 BACK COVER ASS'Y
E750L 750LLU70N05 AU 17" LCD PANEL
AIC782KACG2 MAIN BOARD
40G 457624 1B LABEL-CPU
40G 45762412B CBPC LABEL
C404 67G215C151 4H LOW ESR 150UF 25V 8*7M
C406 67G215C151 4H LOW ESR 150UF 25V 8*7M
C408 67G215C151 4H LOW ESR 150UF 25V 8*7M
C412 67G215C151 4H LOW ESR 150UF 25V 8*7M
CN102 88G 35315FHAS D-SUB 15PIN
CN301 33G801724A H PIN HEADER 24P 2.0mm
CN401 33G8022 6A H HEADER FEMALE 6P
CN402 33G8022 6A H HEADER FEMALE 6P
CN403 33G3802 9H WAFER 9P RIGHT ANELE P
U202 56L1133 42AL7 A2900117-70
X201 93G 22 53 CRYSTAL 14.318MHzHC-49
715L 972 1 6 PCB
C102 65G0603104 12 CER2 0603 X7R 16V 100N
C103 65G0603103 32 0.01UF +-10% 50V X7R
C104 65G0603103 32 0.01UF +-10% 50V X7R
C105 65G0603103 32 0.01UF +-10% 50V X7R
C106 65G0603103 32 0.01UF +-10% 50V X7R
C107 65G0603103 32 0.01UF +-10% 50V X7R
C108 65G0603103 32 0.01UF +-10% 50V X7R
C109 65G0603104 12 CER2 0603 X7R 16V 100N
C110 65G0603390 32 CHIP 39PF 50V
C111 65G0603390 32 CHIP 39PF 50V
C113 65G0603104 12 CER2 0603 X7R 16V 100N
C125 65G0603102 32 1000PF +-10% 50V X7R
C201 65G0603104 12 CER2 0603 X7R 16V 100N
C202 65G0603104 12 CER2 0603 X7R 16V 100N
C203 65G0603104 12 CER2 0603 X7R 16V 100N

AOC QDI TFT1780PSA Specifications

General

Brand	AOC
Model	QDI TFT1780PSA
Category	Monitor
Language	English
