17” LCD Color Monitor QDI TFT1780PSA
3
1. Monitor Specifications
Driving system TFT Color LCD
LCD Panel Size 43.2cm(17.0")
Pixel pitch 0.264mm( H ) × 0.264mm( V )
Viewable angle
140° (H) 140° (V)
Video R,G,B Analog Interface
Input Separate Sync. H/V TTL
H-Frequency 30kHz – 80kHz
V-Frequency 55-75Hz
Display Colors 16.2M Colors
Dot Clock 135MHz
Max. Resolution 1280 × 1024 @75Hz
Plug & Play VESA DDC1/2BTM
ON Mode <45W
EPA ENERGY
STAR®
OFF Mode ≤3W
Input Connector 15-pin D-Sub
Input Video Signal
Analog:0.7Vp-p(standard),
75 OHM, Positive
Maximum Screen
Size
Horizontal : 338mm
Vertical : 270mm
Power Source 100~240VAC,47~63Hz
Environmental
Considerations
Operating Temp: 5° to 35°C
Storage Temp.: -20° to 60°C
Operating Humidity: 10% to 85%
Dimension 407×434×173(W×H×D)mm
Weight (N. W.) 5.2kg Unit (net)
Power Consumption ( Maximum ) 45 Watts
Audio Output
Rated Power 2W rms
(Per channel)
Regulatory Compliance UL, CE, TCO’99
