AOC QDI TFT1780PSA User Manual

17” LCD Color Monitor QDI TFT1780PSA
8
The descriptions for function control LEDS
1.
Contrast Adjust the picture contrast.
2.
Brightness Adjust the picture brightness.
3.
Focus Adjust picture Focus.
4.
Clock Adjust picture Clock.
5.
H. Position Adjust the horizontal position of the picture.
6.
V. Position Adjust the vertical position of the picture.
7.
Auto Center Used to center the picture automatically.
8.
Language Multi-Language selection.
9.
Dos-mode
selected
Dos-mode resolution selection for 720x400 @70Hz and
640x400 @70Hz
10.
Red Adjusts Red intensity.
11.
Green Adjusts Green intensity.
12.
Blue Adjusts Blue intensity.
13. C1 (Warm) Color Set the color temperature to warm white.
14.
C2
(Cool) Color Set the color temperature to cool white.
15.
Reset
Clear each old status of Auto-configuration and re-do
auto-configuration.
16.
Exit Save user adjustment and OSD disappear.
Notice: Generally, DOS mode is set to 720x400@70Hz. Your monitor is optimized for this resolution. If you system
is using another resolution such as 640x400@70Hz, select the DOS mode icon
, then press < or > to select
640x400@70Hz. Then press the MENU button to confirm the selection. Turn the monitor OFF then back ON by
pressing the Power Button to activate the setup.
