AOC U34G3X User Manual

AOC U34G3X
29 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #20 background imageLoading...
Page #20 background image
18
PIP Setting
ExitExtra
Luminance
Color Setup
Size
Position
PIP Setting Off
Main Source
Swap Off
Picture Boost
Sub Source HDMI1
Audio
PIP Setting
PIP
Game Setting
OSD Setup
HDMI2
Small
Off
Right-Up
PIP Setting OFF / PIP / PBP Disable or Enable PIP or PBP.
Main Source HDMI1 / HDMI2 / DP Select main screen source.
Sub Source HDMI1 / HDMI2 / DP Select sub screen source.
Size Small / Middle / Large Select screen size.
Position
Right-up
Set the screen location.
Right-down
Left-up
Left-down
Audio
On: PIP Audio
Disable or Enable Audio Setup.
Off: Main Audio
Swap
On: Swap
Swap the screen source.
Off: non action

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AOC U34G3X and is the answer not in the manual?

AOC U34G3X Specifications

General IconGeneral
Pixel pitch0.2325 x 0.2325 mm
Screen shapeFlat
Backlight typeW-LED
Display diagonal34 \
Surface hardness3H
Anti-glare screenAlways gives an optimal view, even in direct sunlight.
Display technology-
Native aspect ratio21:9
NTSC coverage (typical)85 %
Viewable size, vertical334.8 mm
sRGB coverage (typical)119 %
Contrast ratio (dynamic)80000000:1
Contrast ratio (typical)1000:1
Display number of colors16.7 million colors
Display diagonal (metric)86.36 cm
Viewable size, horizontal799.8 mm
Display brightness (typical)300 cd/m²
Supported graphics resolutions3440 x 1440
High Dynamic Range (HDR) supportedYes
RMS rated power5 W
Number of speakers2
CertificationTrue
Product colorBlack, Red
Front bezel colorBlack/Red
Market positioningGaming
USB hub version3.2 Gen 1 (3.1 Gen 1)
Headphone outputs1
DisplayPort version1.4
Headphone connectivity3.5 mm
USB Type-A downstream ports quantity4
Input current1.5 A
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.5 W
Power consumption (typical)57 W
Tilt angle range-5 - 23 °
Cable lock slot typeKensington
Panel mounting interface100 x 100 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
Exterior finish typeTextured
Package weight11800 g
USB cable length1.8 m
Cables includedAC
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)399.6 mm
Width (with stand)817.4 mm
Height (with stand)529.4 mm
Weight (with stand)8700 g
Depth (without stand)55.7 mm
Height (without stand)370.7 mm
Weight (without stand)7000 g
