AOC U34V5C/BK - Technical Specifications; General Specification Details

26
Specification
General Specification
Panel
Model Name U34V5C/BK
Driving System TFT Color LCD
Viewable Image Size 86.4 cm Diagonal
Pixel Pitch
0.23175mm(H) x 0.23175mm(V)
Others
Horizontal Scan Range 30k-160kHz
Horizontal Scan Size(Maximum) 797.22mm
Vertical Scan Range 48-100Hz
Vertical Scan Size(Maximum) 333.72mm
Optimal Preset Resolution
3440x1440@60Hz
Max Resolution 3440x1440@100Hz (HDMI/DP/USB C*)
Plug & Play VESA DDC2B/CI
Power Source 100-240V~, 50/60Hz, 3A
Power Consumption
Typical(default brightness and contrast) 60W
Max. (brightness = 100, contrast =100)
≤
190W
Power saving
≤
0.5W
USB C
USB-C Double-sided Connectable Plug
Ultra-highSpeed Data And Video Transmission
DP Built-in DP Alt Mode
Power Supply USB PD Version 3.0
Maximum Power Supply Up to 65W (5V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A)
Physical
Characteristics
Connector Type HDMI/DP/USB C/USB×4/Earphone
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (Non-Condensing)
Non-Operating 5% ~ 93% (Non-Condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )
Note:
*: USB C(DP Alt) signal input, and “USB” is set to “High-Res.”, the maximum resolution is 3440x1440@100Hz.
Color bits Limitation:
U34V5C/BK
422/420 444/RGB 422/420 444/RGB 422/420 444/RGB
(HDMI2.0) (HDMI2.0) (DP1.2) (DP1.2)
USBC@
USB3.2
USBC@
USB2.0
USBC@
USB3.2
USBC@
USB2.0
WQHD 100Hz 8 bit
OK OK OK OK NA OK NA OK
WQHD 60Hz 8 bit
OK OK OK OK OK OK OK OK
low resolutions 8 bit
OK OK OK OK OK OK OK OK
