A70PF(RX-777NS) 28 / 33
Exploded Parts List
No. Ref. P/N Description Q’ty Location
1 151-000-H1BLG-A Front Panel 1
2 700-117-2514 CRT 1
3 151-00N-CAJG-B Rear Cover 1
4 900-TSP-XG51 PCB Board 1
5 111-014-0201 Rubber Washer 4
6 899-400-RXP6 Key Board 1
7 154-000-RX17 Adjustor Knob 1
8 105-010-3012 Screw 2
9 152-002-PX17R bracket right 1
10 152-002-X17L bracket left 1
11 105-016-3012 Screw 2
12 105-016-4012 Screw 4
13 151-701-CAJG Stand (Base)Plate 1
14 108-325-5012 Screw 4
15 154-00G-572B-A I/O plate 1
