B. Using crossover cable
When using crossover cable, the connection can be
made from any (MDI-X) ports of the Switch to any port of
the Hub.
Switch to switch (other devices)
This switch can be connected to another switch or other
devices (routers, bridges, etc.) via a two-pair Category 3,
4, 5 UTP/STP straight or crossover cable.
A. Using straight cable
When using straight cable, this is done from the uplink
(MDI-II) port of the Switch (Switch A) to any of the
10Mbps or 100Mbps (MDI-X) port of the other switch
(switch B) or other devices.
B. Using crossover cable
When using crossover cable, this is done from any (MDI-
X) port of the Switch (Switch A) to any of the 10Mbps,
100Mbps (MDI-X) port of the other switch (switch B) or
other devices.
1. The “100LINK/ACT,10LINK/ACT” LED indicator
light green for hookup to 100Mbps speed or light
amber for hookup to 10Mbps speed.
2. The “Full-Duplex/Collision” LED indicator depends
upon LAN card capabilities whether it’ s full-duplex or
half-duplex
