SPECIFICATION
LCD Panel
Driving System TFT Color LCD
Size 21.5”W (55 cm)
Pixel Pitch 0.2745 mm (H) x 0.2745 mm (V)
Brightness 250 cd/m
2
(Typical)
Contrast 3000:1 (Typical)
Viewable Angle 178° (H) 178° (V) (CR=10)
Response Time 5 ms (G to G)
Panel Type VA
H-Frequency 54-84.375 KHz
V-Frequency 48-75 Hz
Display Colors 16.7M Colors
Dot Clock
HDMI: 185 MHz
VGA: 148.5 MHz
Maximum Resolution
HDMI: 1920 x 1080 @ 75 Hz
VGA: 1920 x 1080 @60 Hz
Plug & Play VESA DDCCI/DDC2B
A
* Annual Energy Consumption 26 (kWh) (for HDM I-Input Model)
Power Consumption
(at 200 nits)
On Mode 18 W (Typical)
Off Mode (Stand By) 0.5 W (Typical)
Input Connector
D-Sub
HDMI (Only HDMI-Input Model)
Input Video Signal
Analog: 0.7 Vp-p (standard), 75 OHM, Positive
HDMI (Only HDMI-Input Model) (Optional)
Maximum Screen Size
Horizontal: 476.64 mm
Vertical: 268.11 mm
Power Source INPUT: 100 - 240 V, 50/60 Hz
Environmental Considerations
Operating Temp: 0° to 40°C
Storage Temp: -20° to 60°C
Operating Humidity: 20% to 90%
Dimensions 503 (W) x 379.4 (H) x 180.5 (D) mm
Weight (N. W.) 2.8 kg (net)
Tilt: -5° to +20°
Swivel: No
Height adjustment: No
Pivot: No
Detachable foot stand: Yes
External Controls
Switch/Buttons
Power Button
Hotkey 1
Hotkey 2
Hotkey 3
Hotkey 4
Functions
Brightness
Contrast
Blue Light
Black Boost
ACM
H.Position
V.Position
Focus
Clock
Gamma
Color Temp.
Modes
sRGB Mode
Grayscale Mode
6-axis Hue
6-axis Saturate
Over Drive
Language
OSD Timeout
Transparency
Refresh Rate Num
OSD Lock
Input
Auto Source
Hot Key Assignment
Wide Mode
DDC/CI
HDMI Black Level
Quick Start Mode
Information
Reset All Settings
* Annual energy consumption is calculated using the typica l power consumption 4 hours per day, 365 days per year.
