5
3. Internal Connectors
Front panel
connector
reset connector
CPU socket
Riser Card
connector
Internal
Speaker
Full Size
Mini card slot
LPC1
LPC2 connector
Fan PWR
connector
BIOS
COM1
Half Size
Mini card slot
DIMM socket
Internal USB1/2
Front USB x 2
CARPWR connector
PCH HM65
Front panel
connector
reset connector
Riser Card
connector
Internal
Speaker
Full Size
Mini card slot
LPC1
LPC2 connector
Fan PWR
connector
BIOS
COM1
Half Size
Mini card slot
DIMM socket
Internal USB1/2
Front USB x 2
CARPWR connector
