AOpen DEX5750 Series User Manual

4
2. Product Specification
CPU
Intel 11th Gen Tiger Lake UP3 Core i processor TDP ≦15W
Chipset
NA
Memory
Dual Channel Mode, SO-DIMM DDR4 x 2, 3200, Max memory size : 64GB
Graphics
Intel Iris Xe Graphics (Gen12)
Expansion
Slot
M.2 2230 x 1(key E for wifi), M.2 2242 x 1(key B for SSD)
M.2 2280 x 1(key B for NVMe/PCIe SSD)
Audio
Realtek HD Audio CODEC on-Board.
LAN
Intel GIGA LAN x 1 (i219LM), 2.5G LAN x 1 (i225LM)
Front Panel IO
Power Button x 1 (with Power indicator (Blue) ), HDD indicator (Blue) x 1,
USB 2.0 Port x 2, RS232 x 1, RS232/422/485 x 1
Rear Panel IO
DC 19V Jack x 1, HDMI 2.0 Port x 2, DisplayPort 1.4 x 2, RJ45 LAN Jack x 2, USB 3.0
Port x 4, HD Audio Line out x 1, Mic-in x 1, extend power S.W x 1.
Adapter
90W (19V, 4.74A) AC Power Adapter
Input Voltage
AC 100 ~ 240V
