3. Internal Connectors
Riser Card
connector
VGA2 connector
COM port
connector
Mini Card slot
CPU Socket
North Bridge
GM45
Fan PWR connector
SO-DIMM Socket
PWR SW, LED
HDD LED connector
1 port USB x 2
Front USB x 1
5
